Opengear 4 ports 1GbE, RS-232 Console server Model ACM7004-2-L-GLB

Brand Opengear ,

Model ACM7004-2-L-GLB

Networking / Connectivity Technology Wired,

Networking / Data Link Protocol ,

Ethernet,

Fast Ethernet,

Gigabit Ethernet,

RS-232,

Color

Black,

Red,

Networking / Form Factor External,

Networking / Ports Qty 4,

Networking / Type Console server,

Packaged Quantity 1,

Antenna External detachable,

Antenna Qty 2,

Cellular Band 4G LTE B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B18/B19/B20/B26/B28/B29/B30/B32/B41/B42/B43/B46/B48/B66 / HSPA+ B1/B2/B4/B5/B6/B8/B9/B19

Cellular Protocol HSPA+, LTE,

Generation 4G,

Mobile Broadband Access Yes,

Humidity Range Operating 5 - 90%,

Max Operating Temperature 60 °C,

Min Operating Temperature -25 °C,

Expansion Slots 2 (total) / 2 (free) x Mini SIM card,

Interfaces

4 x RS-232 - RJ-45,

2 x 1000Base-T - RJ-45,

4 x USB 2.0 - Type A,

2 x antenna - SMA,

2 x digital input/output,

2 x digital output,

Depth 12 cm,

Device Type Console server,

Cables Included 1 x DB-9 to RJ-45 adapter,

Compliant Standards EN 55022:2010, CISPR 22:2008, FCC Part 15 Subpart B:2015, ICES-003 issue 5, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2008, EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8:2010, EN 61000-4-11:2004, UL 1950, TUV, C-Tick, RoHS, PCI DSS 3.2, NERC-CIP, FIPS 140-2, AS/NZS CISPR22:2009+A1:2010, FCC, GCF, JRF, JPA, NCC, PTCRB,

Included Accessories Rack mount kit, terminal block connector, 2 x cellular antennas, 4 rubber feet, power adapter, cellular antenna extender,

MTBF 100,000 hours,

Authentication Method TACACS+, Kerberos, RADIUS, LDAP, PAP, CHAP, Secure Shell v.2 (SSH2),

Connectivity Technology Wired,

Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232,

Encryption Algorithm SSL,

Features 4KV AC surge protection, ESD Protector, VPN support, DHCP server, firewall protection, port forwarding, IP address filtering, Sierra Wireless EM7565 modem,

Form Factor External,

Network / Transport Protocol IPSec, OpenVPN, DDNS, TFTP, FTP,

Performance

4G download speed: 600 Mbps,

4G upload speed: 150 Mbps,

Ports Qty 4,

Remote Management Protocol HTTPS, SSH,

Power Device External power adapter,

Voltage Required AC 110-240 V,

Flash Memory 32 MB,

Hard Drive SSD 4 GB,

Max Supported Qty 1,

Processors Installed 1 x Marvell 88F6W11 800 MHz,

RAM 256 MB DDR3 SDRAM,

OS Provided Linux,

Description:

Opengear ACM7004-2-L-GLB - Console server - 4 ports - 1GbE, RS-232 - 4G - 4G LTE B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B18/B19/B20/B26/B28/B29/B30/B32/B41/B42/B43/B46/B48/B66 / HSPA+ B1/B2/B4/B5/B6/B8/B9/B19
