6 Channel 3 pin 4 pin Computer CPU Cooler Case Fan Speed Controller w/ rubber backed Tap for PC Case Internal Installation & Mining Cooling-Power by Molex 4pin

Limited time offer, ends 03/31 By EN Labs Marketplace

(7)(1) Write a Review
See more "pc fan controller"
Check more best sellers of "Controller Panels"
Check more lowest price of "Controller Panels"
Check more deals of "Controller Panels"
In stock.
Ships from United States.
  • 6 channels PC case internal fan speed controller
  • Each fan can be turned off , speed adjusted range 0%~100% full speed
  • Support 3pin and 4pin fan speed controller by voltage adjusted
  • 12V3A max. each channle,support total 120Watt.(12V/10A)output
  • Power by Molex 4Pin or DC12V(5.5x2.1 /5.5x2.5 DC headers)
  • Adhesive tape at the back lets you mount the controller at a convenient place inside the chassis
+
+
Overview
Specs
Reviews
Six-channel 120 Watt. High-Power computer fan speed controller
  • Gain full control of up to six fans, like CPU fan, chassis fan, video card fan, hard disk fan and chipset fan, to achieve a balance of cooling performance and noise levels.
  • This gadget comes with six 4-pin connectors compatible with 3-pin/4-pin fans, works with 12V fans, and includes six dials to adjust each corresponding fan speed from 0% to 100% trough voltage adjustment (not PWM control).
  • A 4-pin Molex connector or DC 12V connector draws power from computer PSU or power adapter to power the gadget and connected fans.
  • Adhesive tape at the back lets you mount the controller at a convenient place inside the chassis.
Features
  • Supports computer parts with cooling fan, including CPU, HDD, DDR, VGA, etc.
  • Power by Molex 4pin female or DC 12V header(5.5*2.1 or 5.5*2.5 connector)
  • Support 6 channels fan speed adjustment individually
  • Each channel can be turned off or adjusted to 100% full speed
  • Adjustable knob available to adjust cooling fan revolution speed for each fan individually
  • Each channel can control 4-pin fan or 3-pin fan (Just voltage adjustable control, NOT PWM CONTROL)
  • Support current 3A max each channel,support total 120Watt.(12V/10A)output
  • 6 Channel computer 3pin / 4pin fan speed controller
  •  Voltage adjustable control, NOT PWM CONTROL
  • Speed controling rang is 0% to 100%
  • Support connected fan shut down



  • Power by molex or DC12V
  • Support DC 12V power adapter equipped 5.5*2.1 or 5.5*2.5 connector
  • High quality power manage IC controller
  • Support 3A max. high power fan's controlling
  • Support total 120 Watt. output( 12V/10A total, the currect is limitted by molex header)
  • Six knobs for controling,6 channels fan speed can be adjusted  individually
Specification
Type 3Pin/4Pin Fan Speed Controller
Controller mothed Voltage adjustment Controller
Input Molex 4pIn / DC 12V
Output 6 x 4Pin / 3Pin Fan
Output Current Current 3A Max. each channel
Output Max. Watt. 120Watt. of total 6 channels
