Alphacool Apex Distroplate Dark Base Pro 901 with Apex Pump - Black (14630)

The Alphacool Apex Distro Plate is the ultimate visual upgrade for the Dark Base Pro 901. Specifically designed for this case, it replaces the front cover and takes any custom water cooling setup to the next level. A must-have for those who want to combine top performance with premium design.

The Alphacool Apex product line stands for absolute perfection. Crafted with premium materials and advanced engineering, the Distro Plate guarantees a truly high-end product. The chrome-plated G1/4" fittings, made from solid brass, prevent leaks caused by cracks as they are not screwed directly into the acrylic. Instead, the two-piece fittings feature an O-ring and interlock during installation, ensuring a secure and reliable seal within the acrylic.

Made from high-grade acrylic glass, the Apex Distro Plate offers a clear view of the water cooling loop. Its integrated aRGB lighting creates an impressive play of colors, perfectly showcasing the case. The Distro Plate is available in two variants that differ only in color. Both the black and white versions perfectly match the Dark Base Pro 901s case colors and blend seamlessly into the design.

The Dark Base Pro 901 case offers numerous customization options, including an inverted layout. The Apex Distro Plate is perfectly adapted to these configurations. To ensure maximum flexibility, the Distro Plate features additional, specially designed ports that can be easily used even when the case's interior is built in an inverted orientation. The Distro Plate replaces the front cover and can be securely and easily mounted using the included M4x16 screws and mounting brackets. For an inverted layout, the Distro Plate must be rotated 180 degrees.

Note: The Apex Distro Plate for the Dark Base Pro 901 is exclusively compatible with this case.

Technical Data
Dimensions (L x W x H)
365,10 x 222 x 86,06mm
Material
Acryl
Volume
433ml
Pump compatibility
VPP/D5
Threads
12x G1/4" + 1x fill port and 1x drain port
Maximum working temperature
60°C
Pressure tested
0,8 Bar
Quantity digital aRGB LEDs
16
Power digital aRGB LEDs
5V
Power connection digital aRGB LEDs
3-pin JST + 3-pin 5V
Weight
3600g
Color
white
Technical data pump
Material pump
synthetic material
Material pump cover
aluminium
Material axle
ceramics
Connections
4-Pin PWM | SATA
Rotational speed
2500 - 4500 RPM
Cable lengths
4-Pin PWM - 48cm | SATA - 48cm
Operating voltage
8-13V DC / 14W IP32
Starting voltage
12V DC
Maximum pumping head
4,25m
Maximum flow rate
340L/h
Maximum working temperature
60°C
Color
black

MANUAL
