New 13.3" FHD IPS LCD Screen for Lenovo S2 500S-13 U31-70 LP133WF2-SPL1 SPL2 1920x1080 30-Pin eDP 60Hz Matte 12-Month Warranty

A cracked, faded, or low-resolution display can make your reliable Lenovo laptop feel outdated. Official repairs can be costly, but the solution is simpler than you think. This premium 13.3 -inch FHD IPS panel is a direct, drop-in replacement for many popular Lenovo models, restoring your device's visual clarity and transforming your user experience.

Compatible Laptop Models:

Lenovo IdeaPad 500S-13ISK (80Q2)

Lenovo IdeaPad 510S-13ISK (80SJ)

Lenovo IdeaPad 510S-13IKB (80V0)

Lenovo U31-70 (80M5 / 80M6)

Lenovo E31-70 (80KX)

Lenovo E31-80 (80MX)

Lenovo ThinkPad S2 (13-inch)

Lenovo ThinkPad 13 (1st/2nd Gen)

Lenovo 700S-13ISK (select models)

Other 13.3 -inch Lenovo laptops using a 30-pin eDP connector

Panel Options (100% interchangeable):

LP133WF2-SPL1 (LG Display) 13.3" FHD (1920x1080), 60Hz, 30-pin eDP, 220 cd/m² brightness, 700:1 contrast ratio, 80/80/80/80 viewing angles, 45% NTSC, matte finish. Used in 500S-13ISK and ThinkPad 13.

LP133WF2-SPL2 (LG Display) 13.3" FHD (1920x1080), 60Hz, 30-pin eDP, 220 cd/m² brightness, 660:1 contrast ratio, 85/85/85/85 viewing angles, 45% NTSC, matte finish. Fully interchangeable with SPL1.

CRITICAL Verify Your Connector Before Ordering

These models use a 30-pin eDP connector located on the bottom right of the screen (when viewed from the back).
This is not compatible with:

40-pin LVDS connectors

40-pin eDP connectors

30-pin LVDS connectors

Please remove your old screen and verify the connector type (30-pin eDP), size ( 13.3" ), and resolution (1920x1080) before ordering. Panels are shipped without brackets, cables, screws, or other mounting hardware please reuse your original parts.

Specifications

:

Specification Detail
Screen Size 13.3 inches
Resolution 1920 x 1080 (Full HD / FHD)
Refresh Rate 60Hz
Panel Type IPS
Interface 30-pin eDP (bottom right)
Connector Pitch 0.4 mm 0.5 mm
Surface Matte / Anti-Glare
Brightness 220 cd/m²
Contrast Ratio 660:1 700:1
Color Gamut 45% NTSC
Touch Non-Touch
What a Cracked or Failing Screen Costs You:

Poor visual experience Distracting lines, dead pixels, or faded colors hinder productivity.

Eye strain Flickering or dim screens cause fatigue during long sessions.

Reduced productivity A damaged screen limits your ability to work effectively.

Outdated visuals A standard HD (1366x768) screen provides significantly less detail and clarity.

Why Choose Our Screen:

Premium LG IPS Panel Not a low-quality copy; a screen that meets or exceeds OEM specifications.

FHD High Resolution Crisp, detailed visuals with 166 PPI pixel density.

Matte Anti-Glare Finish Reduces reflections for comfortable viewing in various lighting conditions.

Easy DIY Installation Standard 30-pin eDP interface with a simple drop-in design. No soldering, no complex modifications.

100% Tested Each screen is inspected before shipping to ensure it is free from defects like dead pixels, bright dots, or lines.

12-Month Warranty Buy with confidence. If anything goes wrong, we've got you covered.

Installation Note:

Disconnect the battery and all power sources.

Remove the bezel (frame) around the screen.

Unscrew the mounting screws on the sides of the screen.

Gently disconnect the 30-pin eDP cable from the back of the screen (connector is on the bottom right).

Attach the cable to the new screen.

Secure the screen with the screws and replace the bezel.

Caution: The display assembly is delicate. We strongly recommend testing the new screen before fully securing it connect the screen, power on the laptop, and verify it displays correctly. Professional installation is recommended if you are not comfortable with DIY repairs. Tools are not included.

What's Included:

1 x Replacement LCD Screen ( 13.3", FHD, IPS, 30-pin eDP)
