New 11.6" HD LCD Screen for HP 11-F011TU dm1-4207au dm1-4208au N116BGE-EA2 1366x768 30-Pin eDP 60Hz Matte 12-Month Warranty

A cracked, faded, or flickering display can make your HP laptop frustrating to use. Official repairs can be costly, but the solution is simpler than you think. This 11.6 -inch HD LED screen is a direct, drop-in replacement for a wide range of HP models, restoring your device to its original visual quality without breaking the bank.

Compatible Laptop Models:

HP 11-F011TU (M4X81PA) 11.6" HD, 30-pin eDP

HP dm1-4207au (B8M78PA) 11.6" HD, 30-pin eDP

HP dm1-4208au (B8M79PA) 11.6" HD, 30-pin eDP

Other 11.6 -inch HP models using a 30-pin eDP connector

NOT Compatible:

HP 2170p uses 11.6" 40-pin LVDS

CRITICAL Verify Your Connector Before Ordering

These compatible models use a 30-pin eDP connector located on the bottom right of the screen.
This is not compatible with:

40-pin LVDS connectors (used by HP 2170p)

40-pin eDP connectors

Please remove your old screen and verify the connector type (30-pin eDP), size ( 11.6" ), and resolution (1366x768) before ordering. Installing a screen with the wrong connector will not work. Panels are shipped without brackets, cables, screws, or other mounting hardware please reuse your original parts.

Specifications

:

Specification Detail
Panel Model N116BGE-EA2 (Innolux / Chi Mei)
Screen Size 11.6 inches
Resolution 1366 x 768 (HD / WXGA)
Refresh Rate 60Hz
Panel Type TN (Twisted Nematic)
Surface Finish Matte / Anti-Glare
Backlight LED
Interface 30-pin eDP (Bottom Right)
Connector Pitch 0.5 mm (Large)
Brightness 220 cd/m² (Typ. )
Contrast Ratio 500:1 (Typ. )
Viewing Angle 45/45/20/45 (Typ. )
Display Colors 262, 144 colors
Touch Non-Touch
What a Cracked or Failing Screen Costs You:

Poor visual experience Distracting lines, dead pixels, or faded colors hinder productivity.

Eye strain Flickering or dim screens cause fatigue during long sessions.

Reduced productivity A damaged screen limits your ability to work effectively.

No OEM support These older models may no longer be supported for official repairs.

Why Choose Our Screen:

Premium Innolux Panel Not a low-quality copy; a screen that meets or exceeds OEM specifications.

Matte Anti-Glare Finish Reduces reflections for comfortable viewing in various lighting conditions.

LED Backlight Bright, energy-efficient illumination for clear viewing.

Easy DIY Installation Standard 30-pin eDP interface with a simple drop-in design. No soldering, no complex modifications.

100% Tested Each screen is inspected before shipping to ensure it is free from defects like dead pixels, bright dots, or lines.

12-Month Warranty Buy with confidence. If anything goes wrong, we've got you covered.

Installation Note:

Disconnect the battery and all power sources.

Remove the bezel (frame) around the screen.

Unscrew the mounting screws on the sides of the screen.

Gently disconnect the 30-pin eDP cable from the back of the screen (connector is on the bottom right).

Attach the cable to the new screen.

Secure the screen with the screws and replace the bezel.

Caution: The display assembly is delicate. We strongly recommend testing the new screen before fully securing it connect the screen, power on the laptop, and verify it displays correctly. Professional installation is recommended if you are not comfortable with DIY repairs. Tools are not included.

What's Included:

1 x Replacement LCD Screen ( 11.6", HD, 30-pin eDP)
