New 15.6" HD/FHD IPS LCD Screen for Lenovo ThinkPad E570 E550C E555 E565 E560 T560 T550 L570 L560 1366x768/1920x1080 30-Pin eDP 60Hz Matte 12-Month Warranty

A cracked, faded, or flickering display can make your Lenovo ThinkPad frustrating to use. Official repairs can be costly, but the solution is simpler than you think. This premium 15.6 -inch HD/FHD LED screen is a direct, drop-in replacement for a wide range of Lenovo models, restoring your device's visual clarity without breaking the bank.

Compatible Laptop Models (Partial List):

Lenovo ThinkPad E570 / E575

Lenovo ThinkPad E550C / E555 / E565

Lenovo ThinkPad E560

Lenovo ThinkPad T560 / T550

Lenovo ThinkPad L570 / L560

Compatible Panel Models (Partial List):

NT156WHM-N42 15.6" HD (1366x768), 30-pin eDP [0L15][11L14]

B156XTN 03.1 / 03.5 / 04.0 15.6" HD (1366x768), 30-pin eDP [11L15-L18]

B156HAN 04.4 15.6" FHD (1920x1080), 30-pin eDP, IPS [1L19][9L5]

LM156LF1L/3L 15.6" FHD (1920x1080), 30-pin eDP, IPS [1L19][9L5]

LP156WF6 SPK1 / SPN1 15.6" FHD (1920x1080), 30-pin eDP, IPS [4L19-L21]

CRITICAL Verify Your Connector Before Ordering

These laptops use a 30-pin eDP connector located on the bottom right of the screen (when viewed from the back), with a 0.5 mm connector pitch [5L11-L14][7L5-L6]. This is not compatible with 40-pin LVDS or 40-pin eDP connectors.

Important Notes:

Lenovo is known for fitting different screen types to the same laptop model. Please remove your old screen and verify the connector type (30-pin eDP), size ( 15.6" ), and resolution (1366x768 or 1920x1080) before ordering [8L9-L10].

Panels are shipped without brackets, cables, screws, or other mounting hardware please reuse your original parts.

These models are all 15.6 -inch non-touch displays. Touchscreen models require a different assembly [3L25].

Specifications

:

Specification Detail
Screen Size 15.6 inches
Resolution 1366 x 768 (HD) or 1920 x 1080 (FHD)
Refresh Rate 60Hz
Panel Type TN / IPS (depending on model)
Surface Finish Matte (Anti-Glare) or Glossy
Backlight LED
Interface 30-pin eDP (Bottom Right, 0.5 mm pitch)
Touch Non-Touch
What a Cracked or Failing Screen Costs You:

Poor visual experience Distracting lines, dead pixels, or faded colors hinder productivity.

Eye strain Flickering or dim screens cause fatigue during long sessions.

Reduced productivity A damaged screen limits your ability to work effectively.

No OEM support These older models may no longer be supported for official repairs.

Why Choose Our Screen:

Premium Replacement Panel A genuine-grade replacement that meets original specifications.

Choose Your Resolution Select HD for budget-friendly replacement or FHD IPS for superior color and viewing angles.

Matte Anti-Glare Finish Reduces reflections for comfortable viewing in various lighting conditions.

Easy DIY Installation Standard 30-pin eDP interface with a simple drop-in design. No soldering, no complex modifications.

100% Tested Each screen is inspected before shipping to ensure it is free from defects like dead pixels, bright dots, or lines.

12-Month Warranty Buy with confidence. If anything goes wrong, we've got you covered.

Installation Note:

Disconnect the battery and all power sources.

Remove the bezel (frame) around the screen.

Unscrew the mounting screws on the sides of the screen.

Gently disconnect the 30-pin eDP cable from the back of the screen (connector is on the bottom right).

Attach the cable to the new screen.

Secure the screen with the screws and replace the bezel.

Caution: The display assembly is delicate. We strongly recommend testing the new screen before fully securing it connect the screen, power on the laptop, and verify it displays correctly. Professional installation is recommended if you are not comfortable with DIY repairs. Tools are not included.

What's Included:

1 x Replacement LCD Screen ( 15.6", as selected)
