ViewEra V172BN2 TFT LCD Security Monitor 17" Diagonal Screen Size, VGA, BNC (1 in / 1 Out), Resolution 1280 x 1024, Brightness 250 cd/m2, Contrast Ratio 1000:1, Response Time 5ms, Built-in Speaker

ViewEra V172BN2 TFT LCD Security Monitor 17" Diagonal Screen Size, VGA, BNC (1 In/1 Out), Resolution 1280 x 1024, Brightness 250 cd/m2, Contrast Ratio 1000:1, Response Time 5ms, Built-In Speaker
The V172BN2 delivers resolution of 1280x1024 SXGA, uses 3D comb filter and 3D De-Interlace to get a sharp and vivid picture, supports BNC connector for security application and integrates one speaker of 2 watts. In addition, V172BN2 can do looping with one BNC Video IN and one BNC Video OUT. The base stand and slim frame design makes the monitor look compact and simple. The V172BN2 provides high display quality, reliability and space-saving.

Specifications

Panel Type: Active Matrix, TFT
LCD Active Screen Area: 337.92 X 270.336 mm
Pixel Pitch: 0.264 X 0.264 mm
Maximum Resolution: 1280 X 1024, SXGA
Resolution Support: VGA, SVGA, XGA, SXGA
Brightness: 250 cd/m2
Contrast Ratio: 1000:1
Response Time: 5 ms
Viewing Angle: 170° (H) / 160° (V)
Display Colors: 16.7M colors
Image Processing: 3D Comb Filter and
De-Interlace Vertical Frequency: 50~75Hz
VGA Input: 15
Pin D-Sub Video Input: 1
CH BNC IN/OUT Audio Input: 1 CH Composite (RCA) Audio (L/R)
Power: DC
In Power Supply: AC
Input: 100-240V~ 1.8A, 50-60Hz
DC DC Output: 12V/ 5.0A
Front Control: Power, Menu, Down, Up, Auto
Image Adjustment OSD Function: Contrast, Brightness, Auto Image Adjust, H. Position, H. Phase, V. position, H. Width, Sharpness, Color Temperature, Hue, Saturation, Flesh tone, OSD position, Language, Recall, Volume
Built-in Speakers: 2W x 1
Adjustable Stand: Tilt
Adjustments Wall Mountable: VESA 75 bracket;
Screw Spec: M4x6
Accessory: Power adapter, power cord, VGA cable, audio cable, User manual
