Motherboard Tester, Post Test Card, Laptop Motherboard Analyzer Card, Motherboard Diagnostic Card Automatic Identification PCI E LED for Maintenance

Feature: 1.
Kit Contents: Laptop motherboard analyzer card kit has 1 diagnostic card, 1 connecting wire, 1 terminal, 1 adapter card, 1 terminal wire, 2 flat cable. 2.
Compatible Ability: The laptop motherboard analyzer card supports PCI E, mini PCI E, LPC. All PCI slots are supported. 3. Simple and Easy to
Use: Motherboard analyzer diagnostic card has high recognition rate, automatic recognition of power module. 4.
Suitable Items: Motherboard analyzer diagnostic card kit is suitable for for Ggigabyte, for for etc. 5.
Versatile: Motherboard analyzer diagnostic card can detect multi channel and multi LED indicators, and can display the status of power supply, motherboard, PCUs, memory, video card and hard disk.
Specification: Item
Type: Post Test Motherboard Analyzer Diagnostic CardColor:
BlackInterface: PCI E, LPC
Support: For for Ggigabyte, for for etc.
Size: 78 x 51.8 mm / 3.07 x 2.04 inThe diagnostic card has the following settings: 1. LPC1 shared high speed channel equals to connect to motherboard 2.0 small pin header plus MINI PCIE. 2. PCI High Speed Channel equals to support all PCI slots. 3. LPC2 shared high speed channel equals to connect to motherboard with 2.54 large pin header plus ultra mini SPI. 4. PCIEX1 high speed channel equals to be able to test gigabyte motherboard without PCI. 5. LPC3 shared high speed channel is equal to connect laptop for MINI PCIE, for A DEBUG converter card for ForASUS DEBUG CON, for EC DEBUG. 6. 3VSB power indicator, check if the power supply is normal. 7. MOBO motherboard indicator, check whether the motherboard is normal. 8. CPU indicator, for checking whether the CPU module is normal. 9. DRAM memory indicator, to check whether the memory module is normal. 10. VGA graphics card indicator, check whether the gr
