XGSPON ONU Stick SFP+ with MAC Optical Transceiver,Version 8311,Compatible Ubiquiti Mikro-TIK Netgate TP Link 10G Switches and Routers SMF 9.953G-TX/9.953G-RX,1270 nm-TX/1577 nm-RX, 20km, SC/APC
- This product is applicable to the Compatible Ubiquiti, MikroTik ,Netgate,TP Link, 10G Switches and Routers,8311 Firmware Version (Supports Web management), Chipset: MaxLinear PRX126 (SMF, 9.953G-TX/9.953G-RX,1270 nm-TX/1577 nm-RX, 20km, SC/APC, DDM)
- Firmware Compatibility: Supports 8311 community firmware.Streamlined device configuration with one-click web setup! Access the interface at 192.168.11.1 using username root (no password required).
- SFP package with SC /APC receptacle High power 1270 nm DML DFB LD and high sensitivity 1577 nm APD,Support 20km transmission distance with SMF,CML-compatible data input/output interface.
- Hot-pluggable capability Low power dissipation < 3W,Case temperature range: -40 degC to 85 degC, Low EMI and excellent ESD protection
- Support of GPON/XGS-PON/NGPON2 standards,256 GEM/XGEM ports, 64 T-CONTs or 16 LLIDs
- Allows configuration of parameters such as PON serial number (ONT ID), Vendor ID, Equipment ID, Logical ONU ID, Logical passw
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
XGSPON ONU Stick SFP+ with MAC Transceiver, 8311 Firmware Version (Supports Web management), Chipset: MaxLinear PRX126 (SMF, 9.953G -TX/ 9.953G -RX, 1270 nm-TX/1577 nm-RX, 20km, SC/APC, DDM)
The XGSPON ONU stick with MAC module is designed for 10G passive optical network systems. The STICK optical module can fully meet the requirements of the carrier-grade FTTB\ FTTH\ FTTO device. It can be hot-swapped into the SFP+ slot of the Layer 2 Ethernet switch. The whole machine can be used as an ONT or even an MDU to connect the entire device to the XGSPON optical network directly. The central office OLT only needs to register the XGSPON ONU STICK optical module as if it were a typical optical CAT. The communication device can complete the access switch from the original P2P.
Custom XGSPON ONU Stick SFP+ Firmware Compatibility: Supports 8311 community firmware.
Hardware Specs: High-performance design with 1 GB RAM for seamless operation.
Customization Support
Allows configuration of the following parameters: PON serial number (ONT ID) Vendor ID Equipment ID Logical ONU ID Logical password MAC address
Product Features Compatible: Ubiquiti Series 10G
Switches Form: XGSPON ONU Stick SFP+ Brand name: FiberMall Single fiber bi-directional data links symmetric TX 9.953 Gb/s / RX 9.953 Gb/s with MAC function SFP package with SC /APC receptacle Single 3.3 V power supply Hot-pluggable capability High power 1270 nm DML DFB LD and high sensitivity 1577 nm APD Support 20km transmission distance with SMF CML-compatible data input/output interface Low power dissipation <3W Low EMI and excellent ESD protection Digital diagnostic monitor interface RoHS-6 compliance Case temperature range: -40 degC to 85 degC Support of GPON/XGS-PON/NGPON2 standards 256 GEM/XGEM ports, 64 T-CON
Ts or 16 LLI
Ds Carrier Grade QoS Engine Advanced loopback and diagnostic capabilities Supports Synchronous Ethernet (SyncE)
Applications Residential home gateway Network switch/router, VDSL MDU, and G. fast DPU Mobile backhaulStandard Complies with ITU-T G. 987.2 Complies with ITU-T G. 9807.1, G. 9807.2 ITU-T G. 988 OMCI L2 MAC Bridge (Up to 64 L2 bridges) G. 8275/Y. 1369/IEEE 1588v2 IEEE 802.1 ag and ITU-T Y. 1731 Ethernet OAM delay & loss measurement hardware support
The XGSPON ONU stick with MAC module is designed for 10G passive optical network systems. The STICK optical module can fully meet the requirements of the carrier-grade FTTB\ FTTH\ FTTO device. It can be hot-swapped into the SFP+ slot of the Layer 2 Ethernet switch. The whole machine can be used as an ONT or even an MDU to connect the entire device to the XGSPON optical network directly. The central office OLT only needs to register the XGSPON ONU STICK optical module as if it were a typical optical CAT. The communication device can complete the access switch from the original P2P.
Custom XGSPON ONU Stick SFP+ Firmware Compatibility: Supports 8311 community firmware.
Hardware Specs: High-performance design with 1 GB RAM for seamless operation.
Customization Support
Allows configuration of the following parameters: PON serial number (ONT ID) Vendor ID Equipment ID Logical ONU ID Logical password MAC address
Product Features Compatible: Ubiquiti Series 10G
Switches Form: XGSPON ONU Stick SFP+ Brand name: FiberMall Single fiber bi-directional data links symmetric TX 9.953 Gb/s / RX 9.953 Gb/s with MAC function SFP package with SC /APC receptacle Single 3.3 V power supply Hot-pluggable capability High power 1270 nm DML DFB LD and high sensitivity 1577 nm APD Support 20km transmission distance with SMF CML-compatible data input/output interface Low power dissipation <3W Low EMI and excellent ESD protection Digital diagnostic monitor interface RoHS-6 compliance Case temperature range: -40 degC to 85 degC Support of GPON/XGS-PON/NGPON2 standards 256 GEM/XGEM ports, 64 T-CON
Ts or 16 LLI
Ds Carrier Grade QoS Engine Advanced loopback and diagnostic capabilities Supports Synchronous Ethernet (SyncE)
Applications Residential home gateway Network switch/router, VDSL MDU, and G. fast DPU Mobile backhaulStandard Complies with ITU-T G. 987.2 Complies with ITU-T G. 9807.1, G. 9807.2 ITU-T G. 988 OMCI L2 MAC Bridge (Up to 64 L2 bridges) G. 8275/Y. 1369/IEEE 1588v2 IEEE 802.1 ag and ITU-T Y. 1731 Ethernet OAM delay & loss measurement hardware support
