Unmanaged 8-Port 2.5G Switch with 2-Port 10G SFP+, Industrial 30W PoE Ethernet Switch Supports IEEE 802.3af/at, 48~57VDC Power Input, -40°F to 176°F
- 8-Port 10/100/1000M/2.5G Base-TXThe switch equipped with 8 10/100/1000M/2.5Gbps RJ45 Port, provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling.
- 2-Port 10G SFP+ Base-FX The switch offers 2 10G SFP+ Base-FX ports for high-speed network connections providing a cost-effective solution in adding 10G link capability.
- 8-Port PoE+ functionThe Switch provides 8-port IEEE802.3af/at PoE+(30W) function for kinds of Powered Devices to receive power as well as data over the RJ-45 cable.
- 48-57VDC Redundant Power InputThe Ethernet Switch requires 48~57V DC power input, In this way, its poe function can be used smoothly.
- Reliable design & Din-rail installationWith its reliable design and ease of use, it is a great choice for integrating networks consisting of network devices such as IP cameras and wireless access points between remote locations.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Overview:
It is an 8 ports 10/100/1000M/ 2.5G Base-TX + 2 port 10G SFP+ Base-FX Hardened PoE switch. The Switch provides 8 port PoE+ function for kinds of Powered Devices to receive power as well as data over the RJ-45 cable. The 10G SFP+ Base-FX supports 1 or 2 core Single-mode or Multi-mode fiber. With its reliable design and ease of use, the product is a great choice for integrating networks consisting of network devices such as IP cameras and wireless access points between remote locations.
Features:
1. 8 10/100/1000M/ 2.5GB ase-TX + 2 10G SFP+ Base-FX
2. 10/100/1000M/ 2.5G bps RJ45 Port Supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
3. Supports IEEE 802.3 at PoE+ (30W per port)
4. Supports 802.3 x Flow Control
5. IEEE 802.3 az Energy Efficient Ethernet (EEE)
6. 48-57VDC Redundant Power Input
7. Industry standard design, dust-proof and close design IP40 Aluminum Case
8. Supports DIN-Rail installation
9. Environmentally hardened -40°C to 80°C (-40°F to 176°F) operating temperature
Specification:
1.
Connector: 8 x RJ45 (10/100/1000M/ 2.5G Base-TX)
2.
Optical Port: 2 x 10G SFP+
3.
Packet Buffer: 2.75M bits
4.
Packet Length: 9K bytes
5.
MAC Address Table: 4K
6.
Processing Type: Store-and-Forward
7.
Forward & Filtering Rate: 14, 880pps (10Mbps), 148, 800pps (100Mbps), 1, 488, 000pps (1000Mbps)
8.
Input Power: 48~57VDC, 6-pin terminal block
9.
PoE Standard: IEEE 802.3 af/at
10. Max. Power per
Port: 30W Max per port (RJ45 Port 1 ~ Port 8)
11.
Power Consumption: 253W Max. (PoE in use), 5W Max. (PoE not in use)
12.
Power PIN Assignment: 1/2(+), 3/6(-) or 4/5(+), 7/8(-)
13.
Certification: CE, FCC, RoHS
14.
Mounting Options: DIN-Rail
15.
Casing: Aluminum Case
16.
Operating Temperature: -40°C to 80°C (-40°F to 176°F)
17.
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
18.
Dimensions (WxDxH): 150 x 115 x 50 mm
19.
Weight: 0.6 kg
Packages:
1* Un-managed 8-port 2.5G PoE RJ45 + 2-port 10G SFP Ethernet Switch
1* Terminal block
1* User Manual
It is an 8 ports 10/100/1000M/ 2.5G Base-TX + 2 port 10G SFP+ Base-FX Hardened PoE switch. The Switch provides 8 port PoE+ function for kinds of Powered Devices to receive power as well as data over the RJ-45 cable. The 10G SFP+ Base-FX supports 1 or 2 core Single-mode or Multi-mode fiber. With its reliable design and ease of use, the product is a great choice for integrating networks consisting of network devices such as IP cameras and wireless access points between remote locations.
Features:
1. 8 10/100/1000M/ 2.5GB ase-TX + 2 10G SFP+ Base-FX
2. 10/100/1000M/ 2.5G bps RJ45 Port Supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
3. Supports IEEE 802.3 at PoE+ (30W per port)
4. Supports 802.3 x Flow Control
5. IEEE 802.3 az Energy Efficient Ethernet (EEE)
6. 48-57VDC Redundant Power Input
7. Industry standard design, dust-proof and close design IP40 Aluminum Case
8. Supports DIN-Rail installation
9. Environmentally hardened -40°C to 80°C (-40°F to 176°F) operating temperature
Specification:
1.
Connector: 8 x RJ45 (10/100/1000M/ 2.5G Base-TX)
2.
Optical Port: 2 x 10G SFP+
3.
Packet Buffer: 2.75M bits
4.
Packet Length: 9K bytes
5.
MAC Address Table: 4K
6.
Processing Type: Store-and-Forward
7.
Forward & Filtering Rate: 14, 880pps (10Mbps), 148, 800pps (100Mbps), 1, 488, 000pps (1000Mbps)
8.
Input Power: 48~57VDC, 6-pin terminal block
9.
PoE Standard: IEEE 802.3 af/at
10. Max. Power per
Port: 30W Max per port (RJ45 Port 1 ~ Port 8)
11.
Power Consumption: 253W Max. (PoE in use), 5W Max. (PoE not in use)
12.
Power PIN Assignment: 1/2(+), 3/6(-) or 4/5(+), 7/8(-)
13.
Certification: CE, FCC, RoHS
14.
Mounting Options: DIN-Rail
15.
Casing: Aluminum Case
16.
Operating Temperature: -40°C to 80°C (-40°F to 176°F)
17.
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
18.
Dimensions (WxDxH): 150 x 115 x 50 mm
19.
Weight: 0.6 kg
Packages:
1* Un-managed 8-port 2.5G PoE RJ45 + 2-port 10G SFP Ethernet Switch
1* Terminal block
1* User Manual
