Taidacent 2.4GHz SX1280 Lora Wireless Communication Module 2.4GHz Dual Antenna Lora RF Transceiver Long-Range Spread Spectrum TOF Positioning Ranging Module

The RF module based on the SEMTECH RF integrated chip SX1280 and SKYWORKS RF front-end SE2431L is a high-performance wireless transceiver for the Internet of Things. Its special LORA debugging method can greatly increase the communication distance and can be widely used in short-range Internet of Things The field of wireless communications. It has the characteristics of small size, low power consumption, long transmission distance, and strong anti-interference ability. The module is not equipped with a micro control chip, which is mainly used for secondary development of customers.
Features Working voltage: 2.0 ~ 3.7V
Working frequency: 2.4 ~ 2.5GH z
Transmit power: 22dBm
Ultra-high receiving sensitivity: -134dBm
Ultra-long effective communication distance: 2 ~ 4Km (visible distance) Adopt LoRa modulation method, compatible with and support FLRC, FSK, GFSK traditional modulation methods Built-in ranging engine, support TOF (Time-of-flight) function Compatible with BLE physical layer SPI communication interface, can be directly connected to various microcontrollers, software programming is very convenient Support dual antenna switchingApplication Smart Home Object tracking, ranging wireless fence Wearable sensors, health and medical Aircraft remote control
