Mean Well HLG-600H-12B Power Supply - 480W 12V 40A - IP67

Features:
Universal AC input (up to 305VAC) / Full range
Protections: Short circuit / Over current / Over voltage / Over temp.
Built-in active PFC function
High efficiency up to 96%
IP67 / IP65 design for indoor or outdoor installations (except for HLG-320H C-Type)
Output current adjustable through output cable or internal potentiometer
Cooling by free air convection
Suitable for LED lighting and street lighting applications
Meet 4kV surge immunity level (IEC61000-4-5)
No load power consumption <0.5W at remote off (HLG-600H)
Type HL LED Driver for use in Class I, Division 2 hazardous location luminaires
LED indicator for power on (HLG-600H A-Type only)
IP67 rated and built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)
7 years warranty
General Specification:
AC input voltage range: 90~305VAC; 127~431VDC
AC inrush current (max. ): Cold start, 70A at 230VAC
Over voltage protection: 110%~140% rated output voltage
Over current protection: 95%~108% constant current limiting, auto- recovery
Setup,
rise,
hold up time: 500ms, 80ms, 15ms at full load and 230VAC
Withstand voltage:
I/P-O/P: 3.75 kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5 kVAC
Working temperature: -40~+70ºC (refer to output derating curve)
Safety standards: UL60950-1, UL8750, ENEC EN61347-1/2-13, EN62384 approved
EMC standards: EN55015, EN55022 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547
Connection Input: UL rated, SJTW 18AWGx3C (30cm)
Connection Output: SJTW 14AWGx2C (30cm) + SJTW 14AWGx2C (30cm) + UL2517 22AWGx3C (30cm) + UL2517 18AWGx2C (30cm)
Dimension (LxWxH) (mm): 280x 144x 48.5
