MEAN WELL EDR-75-12 AC-DC Switching DIN Rail Power Supply 12V 6.3 Amp

AC to DC Switching DIN Rail Power Supply 12 Volts 6.3 Amps 75.6 Watts 12 Volts 6.3 Amps

Specifications

Output Power (W): 75.6 Size (L x W x
H) inches: 1.26 X 4.93 X 4.02
Ripple & Noise (mV p-p): 80 Load
Regulation (±): 1% Line
Regulation (±): 0.5 %
Efficiency: 85.5 %
Agency Approvals: UL/CUL/TUV/CE/CB Universal AC input / Full range Can be installed on DIN rail TS-35/ 7.5 or 15
Protections: short circuit, over voltage, over temperature, overload Cooling by free air convection UL 508 (industrial control equipment) approved EN61000-6-2(EN50082-2) industrial immunity level 100% full load burn-in test 2 year warranty For more 12V power supplies.
Detailed

Specifications

: Primary
Output Voltage (VDC): 12
Output Current (A): 6.3 Maximum
Output Power (W): 75.6
Family: EDR-75
Input Voltage (VAC): 90 to 264
Input Frequency: 47 to 63
Maximum Input Current (A): 1.45 Output
Connector Type: Screw Terminal
Efficiency (%): 85.5
Operating Temperature-Min (Cell): -20
Operating Temperature-Max (Cell): 60
Length (inch): 1.26
Width (inch): 4.93
Height (inch): 4.02
Agency Approvals: UL/CUL/TUV/CB/CE
Color: Silver
Style: DIN.
