WM8960 Audio HAT Module for Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+ Hi-Fi Sound Card HAT Stereo CODEC Playing and Recording I2S Interfac Stereo 3D Surrounding
- 40PIN GPIO extension headerRPi audio hat compatible with Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+
- Integrates WM8960RPi speaker integrates WM8960 low power stereo CODEC, communicates via I2S interface
- MEMS silicon MicIntegrates dual high-quality MEMS silicon Mic, supports left & right double channels recording, nice sound quality
- 3.5mm earphone jackRespeaker 2-mics pi hat onboard standard 3.5mm earphone jack, play music via external earphone; onboard dual-channel speaker interface, directly drives speakers Supports sound effects such as stereo, 3D surrounding, etc.
- Development resources and manualComes with development resources and manual (python demo code for playing / recording)
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Description
This is a sound card HAT designed for Raspberry Pi, low power consumption, supports stereo encoding / decoding, features Hi-Fi playing / recording, what's more, it can directly drive speakers to play music.
CODEC: WM8960
Power supply: 5V
Logic voltage: 3.3V
Control interface: I2C
Audio interface: I2S
DAC signal-noise ratio: 98dB
ADC signal-noise ratio: 94dB
Earphone driver: 40mW (16@ 3.3V )
Speaker driver: 1W per channel (8 BTL)
Packing List
WM8960 Audio HAT x1
8 5W Speaker x1
RPi screws pack (2pcs) x1
This is a sound card HAT designed for Raspberry Pi, low power consumption, supports stereo encoding / decoding, features Hi-Fi playing / recording, what's more, it can directly drive speakers to play music.
Specifications
CODEC: WM8960
Power supply: 5V
Logic voltage: 3.3V
Control interface: I2C
Audio interface: I2S
DAC signal-noise ratio: 98dB
ADC signal-noise ratio: 94dB
Earphone driver: 40mW (16@ 3.3V )
Speaker driver: 1W per channel (8 BTL)
Packing List
WM8960 Audio HAT x1
8 5W Speaker x1
RPi screws pack (2pcs) x1
