Sunhans 4000mW 36dBm 2.4GHz and 5.8GHz IEEE 802.11/a/n/b/g/ac Dual Band UAV WiFi Signal Booster Wireless Signal Amplifier Repeater Extender for House, Office, UAV, IP Cameras, RC Equipment
- Design for simple, 2.4GHz and 5.8GHz dual band wifi signal booster could Auto switch frequency, 4000mW (36dBm) real output power; 5-16V wide voltage range,support different power supply; Aluminum-alloy case by CNC, anti-interference;Designed for Drones, UAV, RC equipment
- Small size and Light weight: the WiFi signal booster have the feature of light weight(318g) and small size: 130mm x 77mm x 24mm), Compatible with any 2.4GHz and 5.8GHz wireless device, Our product can support 2.4GHz and 5.8GHz wireless Router/AP/ wireless bridge/wireless network card
- 2.4GHz and 5.8GHz wireless monitoring(NVR,DVR);2.4GHz and 5.8GHz wireless microphone, RC drones, FPV device etc. For UAV, Routers, IP cameras, R/C helicopters, planes and cars, Walkie talkies, ZigBee, Robot... For House, Office, Hotels, Supermarkets, Hospitals, Parking Spaces... For WiFi Solution and Project : WiFi Hotspot Solutions, Access points, Smart home systems, Smart city IOT, RC Drones Platform, security camera syst
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Features:
2.4 & 5.8 G, Max. 4000mW output power;
Aluminum-alloy case by CNC, anti-interference;
For house, office, UAV, IP cameras, RC equipment....
Technical
Booster model: SHPro5824G4W
Operating range: 2.4 ~ 2.5; 5.0 ~ 5.8 G
Channel width: 20Mhz&40Mhz&80Mhz
Supported standards: IEEE 802.11 b/g/n/a
Operation mode: Bi-directional, half-duplex, time division duplex
Connector type: N-K female
Output power: 4000mW (36dBm)
Input power: 0 ~ 20dBm
Transmit gain: 16 ~ 19dB
Receiver gain: 12dB
Noise figure: 3.5 dB typical
Frequency response: ±1dB over operating range
Power adapter: 12V/2A DC, 100~240V
Operating temperature: -20°Cto +70°C
Operating humidity: Up to 75% relative humidity
Material: Cast aluminum
LED light: Power status LED and activity status LED
Booster size: 130mm x 77mm x 24mm
Booster weight: 318g
Package included:
1 x SHPro5824G4W WiFi booster
1 x power supply
1 x user manual
Instructions on use:
1. Remove the antenna from the wireless device first.
2. Take out the SMA/N cable and connect the wireless device to the TO Radio port of the signal amplifier.
3. Connect the antenna to the other end of the signal amplifier (TO Antenna).
4. Plug in the power and it's done.
2.4 & 5.8 G, Max. 4000mW output power;
Aluminum-alloy case by CNC, anti-interference;
For house, office, UAV, IP cameras, RC equipment....
Technical
Specifications
:Booster model: SHPro5824G4W
Operating range: 2.4 ~ 2.5; 5.0 ~ 5.8 G
Channel width: 20Mhz&40Mhz&80Mhz
Supported standards: IEEE 802.11 b/g/n/a
Operation mode: Bi-directional, half-duplex, time division duplex
Connector type: N-K female
Output power: 4000mW (36dBm)
Input power: 0 ~ 20dBm
Transmit gain: 16 ~ 19dB
Receiver gain: 12dB
Noise figure: 3.5 dB typical
Frequency response: ±1dB over operating range
Power adapter: 12V/2A DC, 100~240V
Operating temperature: -20°Cto +70°C
Operating humidity: Up to 75% relative humidity
Material: Cast aluminum
LED light: Power status LED and activity status LED
Booster size: 130mm x 77mm x 24mm
Booster weight: 318g
Package included:
1 x SHPro5824G4W WiFi booster
1 x power supply
1 x user manual
Instructions on use:
1. Remove the antenna from the wireless device first.
2. Take out the SMA/N cable and connect the wireless device to the TO Radio port of the signal amplifier.
3. Connect the antenna to the other end of the signal amplifier (TO Antenna).
4. Plug in the power and it's done.
