USB to Serial Port Module, USB to 4 Way TTL Module 3.3V 12Mbps Baud Rate UART Serial Port Module UART Transceiver, Serial Adapters
- POWER ON RESET CIRCUIT: The CH9344 chip has built in power on reset circuit, which requires an external 30MHz clock to be provided to the x1 pin during normal operat
- COMPLETE CIRCUIT: CH9344 chip has built in all circuits required by USB bus, including embedded USB2.0 controller and USB PHY, serial matching of USB line, 1.5K pull up resistor required by device, etc.
- PC CONNECTION: UD + and UD pins can be directly connected to PC or other USB host. If the or inductance or ESD device is connected in series for chip ty, the AC DC equivalent series should be within 5.
- CLOCK GENERATION: The clock can be generated through crystal stabilized oscillation through built in inverter of this module. The circuit requires a 30MHz crystal to be connected between pins x1 and X0, with X1 and x0 pins grounded to 20pF oscillating acitor.
- POWER SUPPLY: The CH9344 chip and USB products can directly use 3.3V power supply output by VBUS on the USB bus after LDO stabilization. If the USB product
+
+
