M.2 NVMe SSD to PCI-E x16 Host Controller Expansion Card, 4 x 64Gbps, 4 Port M Key Hard Drive Converter Reader Expansion Card, with LED Indicator, PCIE NVME Adapter (ph44)

PCIE Split/RAID Function: Please Make Sure Your Motherboard Should Supports PCIE Split or PCIE RAID Function, and Supports PCIE 3.0, 4.0 Transmission Protocol, If your computer supports into the BIOS, set the PCI-E for X4 X4 X4 X4, the card will be able to use, please confirm whether the motherboard supports the function of PCI-E split before you buy! If the motherboard does not support splitting, this card is not compatible.
4 LED indicators: 4 hard drives are equipped with 4 LED indicators and the operation is simple and convenient. Four hard drives correspond to four LED displays before the SSD is connected to the LED and the SSD read and write LED can flash. Note: This product can run 4 NWME at the same time, but the motherboard must support PCIE signal sharing.
Comprehensive Data Protection: Adopts solid structure and uses thicker PCB material to stabilize PCIE X16 interface and protect important data. Compatible with a variety of mainstream operating systems, no-drive insta

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

How to
Use: 1. The motherboard supports PCIE split function, which can be set to PCIE X4X4X4 or 4X4 mode. 2. The motherboard supports PCIE RAID function. 3. PCIE to NVME 4 Bay m. 2 M Key SSD to PCI
Ex16 Adapter Card Is plug and play. 4. This adapter support PCIe 4.0 from nvme at full speed. 5. It can be used as long as the motherboard supports splitting.
Specification: Item
Type: Adapter
CardModel: PH44Support
Hard Disk: M. 2 NVME Protocol SSD / M.
2 PCIE EquipmentTransmission Speed: 4 x 64GbpsPakage
List: 1 x Adapter card4 x Mobile stud5 x Screws1 x Screwdriver
