GST160A24-R7B 24V 6.67A 160W Switching Power Supply with Universal Input for Industrial Equipment/LED Lighting/Telecom Systems
- High-Efficiency 24V DC Output: Delivers stable 24V voltage with 6.67A current capacity (160W max power) and 3% voltage accuracy, ideal for industrial automation, LED displays, and telecom infrastructure. 93% conversion efficiency reduces energy waste and heat generation.
- Universal Input & Global Certification: Works with 85-264VAC/120-370VDC input voltage, compatible with worldwide power standards. Features 47-63Hz frequency range and 0.94+ power factor (230VAC) for optimal energy utilization.
- Robust Protection System: Built-in over-voltage (OVP), over-load (OLP), short-circuit (SCP), and over-temperature (OTP) protections ensure safe operation. Withstands 95A/120A inrush current (115VAC/230VAC cold start).
- Low Noise & High Stability: Maintains ultra-low 150mVp-p ripple noise for sensitive electronics. 1% line regulation and 3% load regulation guarantee consistent performance under varying loads.
- Industrial-Grade Reliability: 20ms holdup time ensures continuous operation du
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
The GST160A24-R7B industrial switching power supply provides 24V DC output with 6.67A current capacity (160W max) for demanding applications. Featuring universal 85-264VAC input (120-370VDC compatible), this 93% efficient PSU supports global voltage standards with active PFC (PF> 0.94 @230VAC).
Technical highlights include: 150mVp-p ripple noise for precision equipment, 3% voltage accuracy, and fast 50ms startup time. Protection mechanisms include OVP/OLP/SCP/OTP with auto-recovery function. Certified with CE, RoHS, and meets EN62368 safety standards. The compact metal housing (IP20) operates in -30C to +70C environments with 20-90% RH non-condensing humidity. Includes 20ms power holdup during outages and < 0.75 mA leakage current. Perfect for factory automation, LED video walls, security systems, and telecom base stations.
Dimensions: 199*99*38mm (L*W*H). 5-year MTBF with 2-year warranty support.
Technical highlights include: 150mVp-p ripple noise for precision equipment, 3% voltage accuracy, and fast 50ms startup time. Protection mechanisms include OVP/OLP/SCP/OTP with auto-recovery function. Certified with CE, RoHS, and meets EN62368 safety standards. The compact metal housing (IP20) operates in -30C to +70C environments with 20-90% RH non-condensing humidity. Includes 20ms power holdup during outages and < 0.75 mA leakage current. Perfect for factory automation, LED video walls, security systems, and telecom base stations.
Dimensions: 199*99*38mm (L*W*H). 5-year MTBF with 2-year warranty support.
