FSPDB3A Aluminum Finger-Safe Power Distribution Block, 600VAC/DC, 100kA, 310 Ampere, 3-31/32" Length x 2-17/32" Width x 1-27/32" Height

Captive termination screws
Multiple wire rating
Mersen FSPDBs A new level of safety and ease for installing power distribution blocks. An IP20 level of finger-safe protection is achieved using FSPDBs, eliminating the need for special covers or custom Plexiglas sheets to protect your panels. Modular design also allows for multi pole applications by use of assembly pins. FSPDBs provide a safe, convenient way of splicing cables, splitting primary power into a variety of secondary circuits or providing a fixed junction tap-off point.
Features and benefits: finger-safe protection fully insulated block ensures touch safe isolation of live parts. Recessed termination screws and wire openings provide IP20 grade protection and qualify as finger-safe per IEC 529. Compact modularity single or multiple pole configurations in the most compact footprint. Allows users to build smaller or higher density panels. Snap on DIN-rail mounting sizes 1 to 4 feature integral din rail adaptors allowing for quick and easy installations on 35mm din rail yielding lower installed costs. Captive termination screws unique channel design ensures captive metric wire termination screws. Screws can never be lost. Multiple wire ratings provide users more versatility by offering capability of using multiple conductors in #2 and 2/0 openings. AC and dC ratings have been evaluated for use at 1000V (AC or DC ) provided they are installed on DIN-rails only and with barriers between poles of opposite polarity of sufficient size to maintain required spacing's.
Approvals: UL Recognized Component Guide XCFR2, File
E73571 CSA Certified: Class 6228, File 69363 IEC-947-7-1, 529, 68-2-6, CE Marked. 600VAC/DC voltage rating. 310 ampere current rating. Measures 3-31/32-inches length by 2-17/32-inches width by 1-27/32-inches height.
