Banda Audioparts BD400.4RED Four Channel 4 x 100 Watt Rms Full Range Car Audio Amplfier 4 Ohms Bridged with Optional Use Low or High Pass Filters Red

"SPECIFICATIONS :: Total Power 14,4 @ 2 Ohms : 4 x 100 WRMS
Total Power 14,4 @ 4 Ohms : 4 x 70 WRMS
Total Power 14,4 Bridged @ 2-4 Ohms : 2 x 200 WRMS
Efficiency @ 4 Ohms : 0.84
Efficiency @ 2 Ohms : 0.77
Input Voltage : 9 15V
Input Impedance : 22K Ohms
THD+Noise : 0,10%
"
"SPECIFICATIONS :: THD+Noise : 0,10%
Input Sensitivity : 140mV 680V
SNR : 85dB
Frequency Response : 5 to 22KHz (-3dBs)
HPF (High Pass Filter) : 20 to 90Hz @ 12dB/octave Linkwitz-Riley
LPF (Low Pass Filter) : 90 to 20kHz @ 12dB/octave Linkwitz-Riley
Recommended Fuse : 30 A
Current at Rest : 1 A
Average Current Draw (Sinusoidal) : 30 A
Average Current Draw (Music) : 20 A
Power Wire Gauge (min. Recommended) : 6mm / 9 AWG
"
"SPECIFICATIONS :: SPEAKER WIRE GAUGE (MIN. RECOMMENDED) Weight (Lb) : 1,8
Height (in) : 1,6
Width (in) : 4,8
Depth (in) : 8,0
"
Class D operation provides exceptional power and efficiency, allowing the amplifi
