CF to IDE Adapter Card CF To IDE To 39-pin 40pin 3.5-inch Desktop With Bezel Expansion Card

Features

CF card is a low-cost electronic disk card, which is widely used in notebook computers, personal digital assistants (PDAs)

Boot up your computer using a Compact Flash card with this IDE adapter. Allowing you to access the flash/micro drive media as if it were an IDE hard drive.

39Pin/40-Pin standard male IDE connector, supports CF-I and CF-II types of cards: also supports IBM micro-hard drives with CF-II interface.Standard IDE interface interface: true-IDE mode, and supports DMA-66 transfer mode.

Additionally, this device offers the benefitof no acoustic noise, shock resistance, fast read access time and low power consumption.

The IDE interface is a 40-pin/2.54mm female connector: this card can be directly inserted into the IDE socket.

With LED indicator: power (power LED), CF access (active LED), whether the card is inserted (card detect LED).Master/Slave jumper: can be configured as master or slave.

Use CF card as DOM: automatically supply power from IDE's 20-pin or external floppy drive power socket.

5.0V or 3.3V power supply: choose the appropriate power supply voltage according to your CF cardCan be fixed on the case by screw.

Specifications:

Item: CF to 3.5in IDE Desktop Expansion Card

IDE Connector: 39Pin 40Pin

Size Mixed

Note:

Due to the light and screen difference, the item's color may be slightly different from the pictures.

Please allow 0.5-2 cm differences due to manual measurement.

Package Includes:

1 PC x CF to IDE Adapter with Bezel
