$114.99
Ships from China.
Meet Your Seller
DeLOCK 64055 USB Type-A to Serial RS-422/485 DB9 Adapter with Surge Protection
- Short description: This USB Type-A to RS-422/485 adapter by Delock expands the computer by an industrial interface for machine controls, fieldbus systems, measuring devices, computers, printers etc. Protection features: The adapter protects itself and externally connected devices from electrostatic discharges (ESD) and surges. Extended temperature range The adapter offers high reliability with extended temperature range even in demanding environments. Specification Connectors: Cable: 1 x USB Type-A plug. 1 x Serial RS-422/485 DB9 Male Terminal block: 1 x Serial RS-422/485 DB9 Female 1 x RS-422/485 terminal block 5 pin. Chipset: FTDI FT232R Automatic data flow control. Data transfer: asynchronous, full duplex, half duplex Data transfer rate up to 921.6 Kbps Supports Modbus ± 15 kV ESD protection on all signal pins. Overvoltage protection: 600 W peak pulse (TVS) 3 x LED indicators for power and activity. Case material: plastic. Colour: blue. Operating Temperature: -40°C ~ 85°C Relative humidity: 5 - 95% (non-condensing) Cable length including connectors: approx. 1.5 m. Plug & Play. System Requirements Linux Kernel 4.6 or higher Mac OS 10.14.1 or later Windows 7/7-64/8.1/8.1-64/10/10-64/11. PC or notebook with a free USB Type-A port. Package contents: USB Type-A to RS-422/485 converter Driver CD Terminal block. Packaging: Retail Box.
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Chipset: FTDI FT232R; Automatic data flow control; Data transfer rate up to 921.6 Kbps; 3 x LED display for power and activity;
Colour: blue;
Case material: plastic
Colour: blue;
Case material: plastic
