ADS1256 24bit 8 Channel Analog Digital Converter Module ADC Analog to Digital Signal Converters high Precision Acquisition Data Module Board AD Digital Analog Module
- Product description We delivering products that are designed to elevate your projects to the next level. Whether you are a hardware engineer,hobbyist, student, or professional. Our development boards and components are here to help. Welcome to JESSINIE, for development boards and electronic components. At JESSINIE, we providing a wide range of development board modules, displays, sensors, electronics, power accessories, and DIP sockets to meet your project needs. At JESSINIE, We focus on the importance of reliable and efficient products, we prioritize quality and performance in everything we offer. Choose JESSINIE for your development board and electronic components needs. Thank you for choosing JESSINIE. Product Description ADS1256 8-channel 24-bit ADC module is equipped with TI ADS1256IDB micro-power consumption, high-precision ADC chip and 2.5V reference voltage source, SPI interface communication, data output rate up to 30ksps, support single-ended and differential input Interface Description: 5V, GND:5V power input; SCLK, DIN, DOUT, CS:SPI communication interface; DRDY:ADS1256 data ready output (active low); PDWN:ADS1256 synchronization/shutdown power input (active low level); AIN0-AIN7: The analog voltage input terminal can be used as 8 independent single-ended inputs or 4 groups of differential inputs (the measured voltage should be shared with the module). Since the ADS1256 power supply voltage is 5V and the measured voltage should be 2V lower than the power supply vo
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
On-board high precision ADS1256IDB ADC chip; Onboard ADR03 2.5V power reference chip; The data output rate can reach 30ksps, and the low nonlinearity is 0.0010 %; The module can be configured as 8 single-ended inputs or 4 differential inputs; The ADS1256 module is suitable for measuring analog voltage within 3V, Module operating voltage 5V
