ECS H81H3-A3 LGA 1150 Intel H81 HDMI USB 3.0 ATX Intel Motherboard
- Intel H81
- Core i7 / i5 / i3 / Pentium / Celeron (LGA1150)
- DDR3 1600/1333/1066
Learn more about the ECS (EliteGroup) H81H3-A3
| Brand | ECS |
|---|---|
| Model | H81H3-A3 |
| CPU Socket Type | LGA 1150 |
|---|---|
| CPU Type | Core i7 / i5 / i3 / Pentium / Celeron (LGA1150) |
| Chipset | Intel H81 |
|---|
| Onboard Video Chipset | Supported only by CPU with integrated graphic |
|---|
| Number of Memory Slots | 2x240pin |
|---|---|
| Memory Standard | DDR3 1600/1333/1066 |
| Maximum Memory Supported | 16GB |
| Channel Supported | Dual Channel |
| PCI Express 3.0 x16 | 1 x PCI Express 3.0 x16 |
|---|---|
| PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| Serial ATA (SATA) | 2 x SATA 6Gb/s |
|---|
| Audio Chipset | Realtek ALC662 |
|---|---|
| Audio Channels | 6 Channels |
| LAN Chipset | Realtek 8111G |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x HDMI / 2 x PS/2 / 2 x USB 3.0 / 4 x USB 2.0/1.1 |
|---|---|
| PS/2 | 1 x PS/2 Keyboard 1 x PS/2 Mouse |
| Video Ports | 1 x D-Sub 1 x DVI-D |
| HDMI | 1 x HDMI |
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 4 x USB 2.0 |
| Audio Ports | 3 Ports |
| Onboard USB | 4 x USB 2.0 |
|---|---|
| Other Connectors | 1 x 24-pin ATX Power Supply connector 1 x 4-pin 12V Power connector 1 x 4-pin CPU_FAN connector 1 x 4-pin SYS_FAN connector 1 x 3-pin NB_FAN connector 1 x 3-pin PWR_FAN connector 1 x Speaker header 1 x CLR_CMOS header 1 x Serial port header (COM) 1 x Parallel port header (LPT) |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 7.5" |
| Power Pin | 24 Pin |
| Features | 3 Phase Power Design Applied Solid Capacitor for CPU VRM to ensure a longer lifespan for system ECS Durathon Technology ensure the stability, reliability and performance of system. (Triple Density PCB; Extreme Temp Resistance; 1.5K Marathon Test; Superior Solid CAPs) ESD Protection prevents computers from electrostatic discharge damage to enhance its durability and lifespan Supports GUI UEFI for tweaking BIOS in Graphical interface within a multi language environment ECS MIB III - A friendly interface for overclocking Integrated Printer (LPT) port / header to expand functionality Microsoft Windows 8 Certified Intel 22nm 4th generation Multi-Core CPU support Supports DirectX 11.1 to enhance graphical performance Supports ATI CrossFireX™ to expand your system's graphics capabilities Supports Intel HD Graphics Supports Sound Blaster Cinema technology to deliver cinema-quality picture and sound to home environments ECS Intelligent EZ Utility : eBLU, eDLU, eSF Free Bundle: Norton Internet Security ,CyberLink PowerDVD, CyberLink PowerDirector 9, Muzee with trial version |
|---|
| First Listed on Newegg | May 07, 2014 |
|---|
