Brand | ASRock |
---|---|
Model | Q77M VPRO |
CPU Socket Type | LGA 1155 |
---|---|
CPU Type | Core i7 / i5 / i3 (LGA1155) |
Supported CPU Technologies | Intel Turbo Boost 2.0 Technology Intel K-Series unlocked CPU Hyper-Threading Technology |
Chipset | Intel Q77 |
---|
Onboard Video Chipset | Supported only by CPU with integrated graphic |
---|
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR3 1600/1333/1066 |
Maximum Memory Supported | 32GB |
Channel Supported | Dual Channel |
PCI Express 3.0 x16 | 1 x PCI Express 3.0 x16 |
---|---|
PCI Express 2.0 x16 | 1 @ x4 |
PCI Slots | 2 x PCI Slots |
SATA 3Gb/s | 4 x SATA 3Gb/s |
---|---|
SATA 6Gb/s | 2 x SATA 6Gb/s |
SATA RAID | 0/1/5/10 |
Audio Chipset | Realtek ALC662 |
---|---|
Audio Channels | 6 Channels |
LAN Chipset | Intel 82579LM |
---|---|
Max LAN Speed | 10/100/1000Mbps |
PS/2 | 1 |
---|---|
Video Ports | D-Sub + DVI |
DisplayPort | 1 x DisplayPort |
USB 3.0 | 2 x USB 3.0 |
USB 1.1/2.0 | 6 x USB 2.0 |
Audio Ports | 3 Ports |
Onboard USB | 2 x USB 3.0 + 4 x USB 2.0 |
---|---|
Other Connectors | 1 x IR header 1 x CIR header 1 x Print port header 1 x COM port header 1 x Power LED header 1 x TPM header CPU/Chassis/Power FAN connector 24 pin ATX power connector 8 pin 12V power connector Front panel audio connector |
Form Factor | Micro ATX |
---|---|
Dimensions (W x L) | 9.6" x 9.6" |
Power Pin | 24 Pin |
Features | 100% All Solid Capacitor Design Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory, Max. capacity of system memory: 32GB 1 x PCIe 3.0 x16 Slot, 1 x PCIe 2.0 x16 Slot Supports AMD Quad CrossFireX and CrossFireX Supports Intel HD Graphics with Built-in Visuals Multi VGA Output options: D-Sub, DVI-D and DisplayPort Intel PCIE Gigabit LAN 5.1 CH HD Audio (Realtek ALC662 Audio Codec), Supports THX TruStudio Supports ASRock XFast RAM, XFast LAN, XFast USB, OMG, Internet Flash, UEFI System Browser Supports Intel vPro Technology, Intel Smart Response Technology, Intel Small Business Advantage, Intel Smart Connect Technology, Intel Rapid Start Technology Free Bundle : CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX Multimedia Suite |
---|
Date First Available | May 07, 2012 |
---|
Pros: Seems stable, decent bios, no major complaints. I would definitely buy again.
Cons: As mentioned previously, they don't ship the TPM module with the board. You can order it directly from asrock for 10 dollars with shipping included which isn't bad. They were very nice when I talked to them though.
Overall Review: Also, to the above reviewer. Intel doesn't offer AMT with 'K' processors - this isn't a problem with the motherboard. Everyone should check with the intel spec sheets to confirm their processor supports AMT. I had to get the i5 3570 instead of the 3570k (you don't need a processor to support AMT to use this motherboard, you just can't use AMT without a processor that supports it). Intel AMT is working alright - I can't seem to get KVM with TLS encryption working on the board, but I'll try with the Microsoft AMT software instead of the open source Intel Version. The Asrock support is in California, which is actually helpful. There was no queue for support.
