Question 1

Does this specific MoBo come with a processor?

Accepted Answer

No it doesn't. It supports the LGA 1155 chipset which includes both Sandy Bridge and Ivy Bridge Processors.

Question 2

I'm trying to build my own computer with this motherboard in mind but I can't figure out which power supply or how much Watts is recommended, any suggestions?

Accepted Answer

Picking a power supply mostly depends on what other components you will be using, and how many. Here's the calculator provided by newegg, but there are a bunch of other psu calculators out there. http://images10.newegg.com/BizIntell/tool/psucalc/index.html?name=Power-Supply-Wattage-Calculator

Question 3

will this board accept a double sized vid card like a gtx 760? and is it compatable with the lga 1155 I5-2320?

thanks!

Accepted Answer

I purchased this motherboard for a recent build and viewed ASrock's supported CPU type list for this motherboard. The CPU model you listed is supported.

Regarding your question about the over-sized GTX 760. I am not sure what you mean by over-sized, but...the motherboard only has 1 PCI Express 3.0 slot so it can only handle a single video card not dual video cards. The GTX 760 appears to be a single video card with a fan attachment and extra ports in the back (which is probably what you were referring to). When you plug the GTX 760 card into the motherboard, the fan attachment will cover one of the PCI slots. Case size has to be considered as well as that tends to be the biggest problem. The only potential problem I see, is the PCI express slot is close the memory slots. Not sure if the card would run into that, but the back of the card would be very close to the clips. Keep in mind this answer is just based off of looking at an image of the video card on my monitor and matching the dimensions to the motherboard I own. I don't actually have the video card to test.

I have purchased this motherboard for builds that users will mainly use for home publishing or web based apps. It is good for casual gaming, but I cannot recommend for hardcore gaming.

Question 4

I’m having issues booting:
There is no video, POST or beeps out of SPEAKER1.
I can see CPU_FAN1 and CHA_FAN1 fans working.
I have re-sat the cpu and memory to assure everything is correctly set.
I also couldn't find information about beep codes in the manual.

Has anyone else experienced this? What can I do?

My Build:
- Intel Core i5-3470 Ivy Bridge 3.2GHz (3.6GHz Turbo Boost) LGA 1155 77W Quad-Core Desktop Processor Intel HD Graphics 2500 BX80637i53470

- Mushkin Enhanced Redline 8GB (2 x 4GB) 240-Pin DDR3 SDRAM DDR3 1600 (PC3 12800) Desktop Memory Model 996981

- ASRock B75M-GL R2.0 LGA 1155 Intel B75 SATA 6Gb/s USB 3.0 Micro ATX Intel Motherboard with UEFI BIOS

- SILVERSTONE Strider Plus ST50F-P 500W ATX 12V v2.3 & EPS 12V 80 PLUS BRONZE Certified Full Modular Active PFC Power Supply

Accepted Answer

From ASRock site

Condition	Beeps Code	Debug Code  Normal

1 short beep after POST	With goodnight LED enabled, debug code will disappear after the beep.

Bad CPU	No beep	No debug code

Bad memory	No beep	45

Without memory	3 long beeps	53

Without CPU	No beep(No Power)	No debug code

Without VGA card	5 long beeps	Beeps at”d6”, then show "0d"

Also found this: does the motherboard not have the warning lights? most modern ones don't beep and instead cycle through a bunch of lights on the motherboard then if there is a problem it sits with a red light on where your problem is.

Question 5

I am looking for a replacement to my gigabyte z68 board that i scratched traces on. Tried repairing the traces without success. I have a hyper 212 cpu cooler and 6870 graphics card. Will the 212 have enough clearance?

Accepted Answer

The hyper 212 rises straight up away from the board. The clearance issue is going to depend on what kind of case you are installing this into. The component profile on the surface of the B75M is smaller than the z68. It will support any LGA 1155 socket cooler that the z68 can.

Question 6

does this motherboard come with support for ivy bridge processors or does it need a bios update?

Accepted Answer

Yes it does. It will also support Xeon E3's with socket 1155. Bios comes with a very nice interface that allows you to use a mouse as well. Supports hyperthreading and turbo boost right out of the box.

Question 7

is this motherboard compatible with a 250 watt power supply?

Accepted Answer

A 250 watt supply will probably run it if you never put a lot of stress on the processor and have no USB devices attached that require power.   I use no less than a 600 watt supply on anything I build. It is better to have it and not need it than need it and not have it.

CPU Socket Type	LGA 1155
CPU Type	Core i7 / i5 / i3 (LGA1155)
Supported CPU Technologies	Supports Intel Turbo Boost 2.0 Technology Supports Intel K-Series unlocked CPU Supports Hyper-Threading Technology

Number of Memory Slots	2x240pin
Memory Standard	DDR3 2200(OC)/1600/1333/1066
Maximum Memory Supported	16GB
Channel Supported	Dual Channel

PCI Express 3.0 x16	1 x PCI Express 3.0 x16
PCI Express 2.0 x16	1 @x4
PCI Slots	2 x PCI Slots

Audio Chipset	Realtek ALC662
Audio Channels	5.1 Channels

LAN Chipset	Realtek 8111E
Max LAN Speed	1Gbps

ASRock B75M-GL R2.0 LGA 1155 Intel B75 USB 3.0 Micro ATX Intel Motherboard with UEFI BIOS

Learn more about the ASRock B75M-GL R2.0

Customer Reviews of the ASRock B75M-GL R2.0

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Back I/O Ports	2 x PS/2 / 2 x USB 3.0 / 4 x USB 2.0/1.1
PS/2	2
Video Ports	D-Sub + DVI
USB 3.0	2 x USB 3.0
USB 1.1/2.0	4 x USB 2.0
Audio Ports	3 Ports

Onboard USB	2 x USB 3.0 + 4 x USB 2.0
Other Connectors	1 x IR header 1 x CIR header 1 x Print port header 1 x COM port header 1 x Chassis Intrusion header 1 x CPU Fan connectors (4-pin) 1 x Chassis Fan connector (4-pin) 1 x Power Fan connector (3-pin) 24 pin ATX power connector 4 pin 12V power connector Front panel audio connector

Form Factor	Micro ATX
Dimensions (W x L)	9.6" x 8.4"
Power Pin	24 Pin
