Thecus N7700+ Diskless System Network Attached Storage

(2) Write a Review
  • Desktop
  • Diskless System
  • Intel Celeron-M Technology Processor
  • 2 x 10/100/1000M
  • 4 x USB2.0
Specs
Reviews (2)
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Thecus N7700+

Model
Brand Thecus
Model N7700+
Configuration
Ports 1 x eSATA / 2 x 1GbE / 4 x USB 2.0
Interfaces
Port RJ-45 2 x 10/100/1000M
Port USB 4 x USB2.0
Port eSATA 1 x eSATA II
Port Others 1 x (PCI-e x 8 slot)
HDD Interface 7 x SATA (7 x Bay)
Configuration
Form Factor Desktop
Operating System Client OS support:
- Windows 2000/XP/2003/Vista/7
- UNIX/Linux
- Mac OS 9 / X
Processor Intel Celeron-M Technology
Installed Memory 2GB DDR2 SDRAM
Hard Drive Performance
Included HDD Capacity Diskless System
RAID RAID 0, 1, 5, 6, 10, and JBOD
Convenience
Supported Protocols Transport Protocols: TCP/IP/Appletalk
File Protocols: SMB/CIFS, HTTP/HTTPS, FTP, NFS v3, AFP
LEDs Power(Blue)
System Status: Busy (FW Upgrade)(Orange)
HDD1-7 Activity/Fail(Green/Red)
WAN (Link: Green; Activity: Green)
LAN (Link: Green; Activity:Green)
USB (Copy LED: Blue)
eSATA (Activity LED: Blue)
Power
Power 300W Power Supply
Environmental
Temperature 5°C - 40 °C
Humidity 0-80% RH non-condensing
Features
Features Ready For the Future
Future technologies are around the corner, and the N7700+ is ready. With its PCI-e slot, the N7700+ can accommodate a number of emerging technologies. Add a 10Gb Ethernet adaptor and experience the lightning-fast file transfers. With PCI-e expansion, the N7700+ is ready for whatever may come.

Unique Dual DOM Design
In business, having access to mission-critical data at all times is crucial. The N7700+ is equipped with a dual Disk On Module (DOM) design to ensure flawless operation and maximum uptime.

Stackable Storage and iSCSI Ready
The N7700+ supports iSCSI initiators, which allows servers to access it as a direct-attached-storage device over LAN or Internet with excellent transfer speeds. With this capability, users can centrally manage and deploy storage for their entire network. In addition, the N7700+ is also stackable, enabling users to connect their unit with up to five additional N7700+s via a master system as a large data pool. With iSCSI and stackability, expanding the capacity of application servers is both quick and easy.

Maximum Flexibility and Expansion
Aside from being iSCSI ready, the N7700+ offers unmatched flexibility. Support for multiple file systems including Ext3, XFS and ZFS, as well as online RAID migration and expansion, means that the N7700+’s data protection and capacity are upgradable and can be integrated into virtually any company network with ease. Users can add larger hard disks to available slots and join an existing RAID volume. The N7700+ will automatically rebuild the RAID array and increase storage capacity.

Handy Snapshot Feature for Version Control
The N7700+ is capable version control via a snapshot function with the ZFS file system, allowing users to efficiently create and restore remote backups. For users, the result is total data security and peace of mind.
Additional Information
First Listed on Newegg May 07, 2010

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 2 years
  • Limited Warranty period (labor): 2 years
