ZyXEL P660R-D1 ADSL 2+ Router 1 x ADSL WAN Ports 1 x 10/100Base-TX LAN Ports

Be the first to review this product...
  • 1 x ADSL WAN Ports
  • 1 x 10/100Base-TX LAN Ports
Specs
Reviews

Learn more about the ZyXEL P660R-D1

Model
Brand ZyXEL
Model P660R-D1
Details
Protocols IEEE 802.1d Transparent Bridging
802.1q Pass-through Bridge
Up to 256 MAC Learning Address
IP Routing: TCP, UDP, ICMP, ARP
RIPv1 and RIPv2
Static Route
IP Multicast IGMP v1/v2
IP Policy Route
Security Password-protected System Management Terminal
PAP(Password Authentication Protocol)
CHAP(Challenge Handshake Authentication Protocol)
Microsoft CHAP
IP Packet Filtering for Access Control
WAN Ports 1 x ADSL
LAN Ports 1 x 10/100Base-TX
LEDs Status LEDs Indicator
VPN Yes
Temperature 0°C - 40°C
Humidity 20% ~ 85%
Features
Features ZyXEL's P-660R Compact Series is the next generation of compact routers capable of speeds up to 12Mbps (ADSL2) and 24 Mbps (ADSL2+).

Enabling high-speed Internet connections, the P-660R is designed for small office, home office, and residential users.

Enjoy ADSL services and broadband multimedia applications such as interactive gaming, video streaming, and real-time audio easier and faster than ever before.

ADSL Compliance:
RADSL (ANSI T1.413 Issue 2)
G.dmt ADSL over POTS (G.992.1 Annex A)
G.dmt ADSL over ISDN (G.992.1 Annex B and U-R2)
G.lite (G.992.2)
G.hs (G.994.1)
Auto-negotiating rate adaptation
ADSL2 G.dmt.bis(G.992.3)
ADSL2 G.lite.bis(G.992.4)
ADSL2+ (G.992.5)
Reach Extended ADSL(RE ADSL)

ATM Supports:
8 PVCs Support
RFC 1483/2684 Multiple Protocol over AAL5
VC and LLC Multiplexing
Traffic Shaping UBR,CBR,VBR-nrt
ATM Forum UNI 3.1/4.0 PVC
I.610 OAM F4/F5 loop-back, AIS, and RDI OAM cells

PPP Support:
PPP (RFC 1661)
PPP over AAL5 (RFC 2364)
PPP over Ethernet (RFC 2516)
PAP Authentication (RFC 1334)
CHAP Authentication (RFC 1994)

Advanced:
Traffic Redirect
Zero Configuration
Call Scheduling
Budget Management
Multimedia Auto Provisioner

ADSL: One RJ-11 or RJ-45
LAN: One Port Switch,10/100M Auto MDI/MDIX
Reset Button
Power 9V

IP Management:
SUA (Single User Account)
Multi-NAT (Network Address Translation)
Multimedia Support
VoIP SIP Pass-through
VPN ( IPSec,PPTP,L2TP Pass-through
DHCP Server/Relay/Client
IP Alias
DNS Proxy
Dynamic DNS
UPnP Support

Network Management:
Web-based Configuration
Command-line Interpreter(CLI)
Telnet Remote Management
SNMP MIB Support
FTP/TFTP firmware upgrade and configuration backup/restore
Built-in Diagnostic Tool
Dimensions & Weight
Dimensions 1.38" x 4.33" x 4.21"
Weight 5.68 oz
Additional Information
Date First Available May 20, 2011
