Vertiv Liebert AS4C0NCWGNNXLKB APS 15kVA Scalable to 20kVA N+1| 208V Single Phase Modular UPS - 15 Minutes Full-Load Runtime| Online Double Conversion UPS | Rack/Tower | Factory Installed SNMP/Webcard

Status Indicators LCD Display
Backup/Run Time (Half Load) 39 Minute
Backup/Run Time (Full Load) 15 Minute
Battery Characteristics Valve Regulated Lead Acid (VRLA)
Form Factor Rack/Tower
Height 38"
Width 17"
Depth 34"
Application/Usage: Mission Critical Equipment, Room
Plug/Connector Type Hard Wire 3-wire (L-L-G)
Phase Single Phase
Network (RJ-45) No
Modem (RJ-11) No
Serial Port Yes
EPO Port Yes
USB (HID Compliant) Port Yes
Auto Shutdown Software: Trellis™ Power Insight
Extra Power for Future Expansion: 20kVA/18kW N+1
VGA: No
Hot Swappable: Yes
Relative Humidity: 0 - 95%, non-condensing
Altitude: 3000 (10000) @ 25°C (77°F)
Battery Capacity: 36W @ 15min-rate to 1.67V per cell @ 25°C (77°F)
Maximum Charge Current (full load): Power module internal charger: 1.8A / Charger module: 10A
Nominal Voltage: 144 VDC
Environmentally Friendly Yes
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
Restriction of Hazardous Substances (RoHS) 2
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Input Voltage 230 V AC
Output Voltage 240 V AC, 100 V AC
Input Voltage Range 120 V AC - 280 V AC
Output Frequency 60 Hz
Input Frequency 70 Hz
Load Capacity (VA) 15 kVA
