OUT OF STOCK

• Status Indicators LCD Display
• Application/Usage Mission Critical Equipment
• Plug/Connector Type Hard Wire 4-wire (L-L-N-G)
• Phase Single Phase
• Maximum Operating Temperature 104°F (40°C)
• Environmental Sensors: Temperature Sensor, Leak Detection Sensor, Humidity Sensor
• Form Factor Rack/Tower
• Height 49"
• Width 17"
• Depth 34"
• Battery Chemistry Lead Acid
• Hot Swappable Yes
• Backup/Run Time (Half Load) 16 Minute
• Backup/Run Time (Full Load) 5 Minute
• Battery Characteristics Valve-regulated
• VGA No
• Network (RJ-45) No
• Modem (RJ-11) No
• Serial Port Yes
• EPO Port Yes
• USB (HID Compliant) Port Yes
• Auto Shutdown Software: Trellis™ Power Insight
• Extra Power for Future Expansion: 20kVA/18kW N+1
• Relative Humidity: 0 - 95%, non-condensing
• Altitude: 3000 (10000) @ 25°C (77°F)
• Battery Capacity: 36W @ 15min-rate to 1.67V per cell @ 25°C (77°F)
• Maximum Charge Current (full load): Power module internal charger: 1.8A / Charger module: 10A
• Nominal Voltage: 144 VDC
• Output Voltage: 200/100 - 240/120VAC
• Environmentally Friendly Yes
• Environmental Compliance Waste Electrical and Electronic Equipment Directive (WEEE)
• Restriction of Hazardous Substances (RoHS) 2
• Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
• Input Voltage 230 V AC, 120 V AC
• Input Voltage Range 120 V AC - 280 V AC
• Output Frequency 60 Hz
• Input Frequency 70 Hz
• Load Capacity (VA) 5000 VA
