Learn more about the TYAN B7129F83AV8E4HR-N-8H100
Model| Brand | TYAN |
|---|
| Model | B7129F83AV8E4HR-N-8H100 |
|---|
Details| Workload | AI/ML/HPC Server |
|---|
| Type | Small Form Factor |
|---|
| Rack Height | 4U |
|---|
| LEDs | (1) HDD / (1) ID / (1) System Event / (2) LAN activity |
|---|
Processor| CPU Type | Intel Xeon Platinum |
|---|
| CPU Speed | 8380 (2.30 GHz) |
|---|
| CPU Socket | LGA 4189 |
|---|
| Number of CPU Cores | 40-Core Processor |
|---|
| Cache Memory | 60 MB |
|---|
| # of Processors Installed | 2 |
|---|
Memory| Installed Memory Size | 256GB |
|---|
| Memory Type | DDR4 |
|---|
| Max Memory Capacity | 8TB |
|---|
| Memory Features | Up to 4,096GB RDIMM/ 8,192GB LRDIMM/ 8,192GB RDIMM 3DS/LRDIMM 3DS
*Follow latest Intel DDR4 Memory POR |
|---|
| Number of Memory Slots | 32 |
|---|
Graphic Controller| Graphic Type | 8 x NVIDIA Tesla H100 80GB |
|---|
Networking| Ethernet Controller | Realtek RTL8211E |
|---|
| LAN Ports | 1 x Ports |
|---|
Expansion & Ports| Expansion Slots | (3) PCIe Gen.4 x16 slots (FH/HL) / (10) PCIe Gen.4 x16 slots (FH/10.5"L/DW)
(1) PCIe Gen.4 x16 OCP 3.0 slot for mezz. w/ pull tab |
|---|
| Expansion Bays | (3) SFF-8643 for (12) front SATA drives |
|---|
Environmental| Temperature | Operating Temp.: 10°C ~ 35°C (50°F~ 95°F)
Non-operating Temp.: - 40°C ~ 70°C (-40°F ~ 158°F) |
|---|
| Humidity | 90%, non-condensing at 35° C |
|---|
Dimensions & Weight| Dimensions | 6.9" x 17.26" x 32.68" |
|---|
| Weight | 101.4 lbs. |
|---|
Additional Information| Date First Available | October 26, 2023 |
|---|
