Rockford Fosgate 10 Inch Prime Dual 500 Watt Car Audio Power Subwoofer R2D4-10
- 10 inch prime R2 subwoofer
- Power handling (max): 500 watts
- Power handling (RMS): 250 watts
- 12 gauge compression terminals
- Integrated PVC trim ring
- Liner spider with embedded 16 gauge tinsel leads
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Rockford Fosgate R2D4-10 10" 500W Car Subwoofer
Sonic Electronix is now carrying the brand new line of Rockford Fosgate Prime Series Car Audio Subwoofers. The R2D4-10 10" subwoofer has a peak power rating of 500 watts and a continuous RMS power rating of 250 watts. This makes this an ideal subwoofer for anyone looking to add some bass to their car audio system. Equipped with anodized aluminum voice coil formers for extreme heat dissipation, will allow this sub to perform at optimum level during long hard hitting sessions. Perfect for sealed or ported enclosures the R2D4-10 is the way to go when looking for Prime performance with an affordable price tag.
Anodized Aluminum Voice Coil Former
By using an anodized aluminum voice coil former on their subwoofers, Rockford Fosgate is able to dissipate heat from the voice coil more efficiently. A hot voice coil can melt the adhesive bonds, which will lead to eventual subwoofer failure. The aluminum voice coil former acts as a heat-sink to dissipate thermal build-up on the voice coil cool during high SPL conditions.
Conforms to CEA-2031
Rockford Fosgate has built this subwoofer to conform to the CEA-2031 loudspeaker power handling industry standards. This means that you can trust the subwoofer to have the capacity to safely handle the continuous (RMS) power rating. Having a CEA-2031 power handling is important when matching a subwoofer to an amplifier because the power ratings are accurate.
Stitched Tinsel Leads
To improve the reliability and performance by reducing fatigue and possible shorting, Rockford Fosgate has stitched the tinsel leads to the spider. The multipoint periodic stitching lead wires reduce the mass of the tinsel leads to spread the stress over a greater area. This improves the reliability and performance of the subwoofer.
General Features:
- 10" Dual 4 ohm Prime Series Subwoofer
- Power Handling:
- Peak: 500 watts
- RMS: 250 watts
- Recommended power range: 175 - 300 watts RMS
- CEA-2031 Compliant
- Klippel Verified
- 12 AWG compression terminals
- Mica-injected polypropylene cone
- Black raised surround
- Linear spider with 16 AWG woven tinsel leads
- StampCast basket with integrated spider venting
- CEA-2031 Compliant accurate power handling rating
- Designed for use with sealed and vented enclosures
- High temperature 2" voice coil
- Integrated PVC trim ring
- Anodized aluminum voice coil former
- Mounting Depth: 4.319"
- Cutout Diameter: 9.125"
- Magnet Weight: 43oz
- Frequency Response: 45 - 250 Hz
- Xmax: 6.5mm
- Sensitivity: 87 dB @ 1 watt / 1 meter
- Recommended Ported Enclosure: 1.40 cubic ft
- Recommended Sealed Enclosure: 0.59 cubic ft
- Matching Amplifiers: (one subwoofer)
- Rockford Fosgate R250X1, Parallel @2ohms
Preferred Match - Rockford Fosgate P300X1, Parallel @2ohms
- Rockford Fosgate PBR500X1, Parallel @2ohms
- Rockford Fosgate P500X1BD, Parallel @2ohms
- Rockford Fosgate R250X1, Parallel @2ohms
- Matching Amplifier: (two subwoofers)
- Rockford Fosgate R1200-1D, Series/Parallel @4 ohms
Preferred Match - Rockford Fosgate P500X1, Parallel @1ohm
- Rockford Fosgate R1200-1D, Series/Parallel @4 ohms
- Authorized Internet Dealer
- 1-year Manufacturer's Warranty
The Rockford Fosgate 10 Inch Prime R2 500 Watt 4 Ohm DVC Subwoofer pumps out awesome bass due to the mica injected polypropylene cone, and the Dual Voice Coil design gives you amazing installation flexibility. This subwoofer uses an anodized aluminum voice coil former that provides superior heat dissipation (up to 100° at max power levels). It has the capacity to handle power under continuous demand, conforming to CEA 2031 industry standards, and the stitched tinsel leads improve reliability and performance by reducing fatigue and possible shorting.
The R2D4 10 also features: 12 gauge compression terminals, an integrated PVC trim ring, a liner spider with embedded 16 gauge tinsel leads, and a StampCast basket with integrated spider venting that keeps the motor cool. This sub is best suited for sealed or vented enclosures. Receive the bass response and installation flexibility you desire with the Rockford Fosgate R2D4 10 Prime R2 Subwoofer!
The R2D4 10 also features: 12 gauge compression terminals, an integrated PVC trim ring, a liner spider with embedded 16 gauge tinsel leads, and a StampCast basket with integrated spider venting that keeps the motor cool. This sub is best suited for sealed or vented enclosures. Receive the bass response and installation flexibility you desire with the Rockford Fosgate R2D4 10 Prime R2 Subwoofer!
- 10 inch prime R2 subwoofer
- Power handling (max): 500 watts
- Power handling (RMS): 250 watts
- 12 gauge compression terminals
- Integrated PVC trim ring
- Liner spider with embedded 16 gauge tinsel leads
- Anodized aluminum voice coil former
- StampCast basket with integrated spider venting
- Mica injected polypropylene cone
- Optimized for sealed and vented enclosures
- CEA 2031 Compliant
- Nominal impedance: Dual 4 ohm
- Voice coil diameter: 2 inches
- Magnet weight: 43 ounces
- Speaker connector: Dual 12 gauge compression
- Re: 7.83 ohms
- Le: 3.9 mH
- Qms: 6.44
- Qes: 0.58
- Qts: 0.53
- Vas: 38.4 (Liters)
- Sd: 339.8 (cm2)
- Xmax: 6.5 mm
- Frequency: 34.9 Hz
- Sound Pressure Level (SPL): 86.6 (dB at 1w/1m)
- Cutout diameter: 9.125 inches (232 mm)
- Mounting depth: 4.319 inches (109.7 mm)
- Woofer displacement: 0.039 cubic feet (1.10 liters)
- Dimensions: 10 inches
- Weight: 8.8 pounds
- Manufacturer warranty: 1-year warranty
