Quick View
Ubiquiti Networks airFiber 5XHD (AF-5XHD)- Frequency Band: Max. TX power* 29 dBm
*Depends on regional regulations.
Frequency accuracy ± 2.5 ppm without GPS Synchronization
± 0.2 ppm with GPS Synchronization
Channel bandwidth 10/20/30/40/50/60/80/100 MHz selectable
Programmable Uplink and Downlink duty cycles
Operating Frequency (MHz)
Worldwide 4800 - 6200 MHz*
*Depends on regional regulations.
US/ CA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3
5150 - 5250 MHz
5250 - 5350 MHz
5470 - 5725 MHz
5725 - 5850 MHz
- LEDs: N/A
- Power Supply: Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Passive PoE 2-pairs (4, 5+; 7, 8-) or (1, 2+; 3, 6-)
Power supply 24V, 1A gigabit PoE adapter (Included)
Supported voltage range 18—54V DC
Max. power consumption 12W
- Temperature: -40 to 55° C (-40 to 131° F)
- Model #: AF-5XHD-US

Quick View
AP-RRP4ATX5062 500W IEC 62368-1 Compliance Certified
Mini Redundant with Active PFC, Hot-Swap- Type: Redundant Power Supply
- Main Connector: 24Pin
- Output Current: +3.3V@20A, +5V@20A,+12V@40A, +5Vsb@3A,[email protected],[email protected],
- Output: +3.3V, +5V,+12V, +5Vsb, -12V, (-5V Option)
- Model #: AP-RRP4ATX5062
