Frequency Band: RF
Operating frequency* 57–66 GHz
* Depends on regulatory region.
Channel bandwidth 2160 MHz/4320 MHz (With channel bonding enabled)
Operating channels 58320, 59400, 60480, 61560, 62640, 63720, 64800 MHz*
*Depends on the channel bandwidth.
Polarization Vertically linear
Beamwidth Azimuth: 3 dB 1.6°
Elevation: 3 dB 1.6°
Back-Up RF
Operating frequency*
US/CA
U-NII-1 5150 - 5250 MHz
U-NII-3 5725 - 5850 MHz
Worldwide 5150–5875 MHz
*Depends on regulatory region.
Channel bandwidth 20/40/80 MHz
Polarization Dual-linear
Beamwidth Azimuth: 3 dB 5°
Elevation: 3 dB 5°
LEDs: Power Flashing white: bootup in progress
White: not connected to UISP™ console
Blue: connected to UISP console
Ethernet Flashing blue: ethernet activity
GPS Blue: receiving at least (4) GPS satellite signals
60G Blue: active connection
5G Blue: active connecti...
Primary Ports: 1 x RJ45 Serial Port
5 x 10/100/1000 Ethernet Router Ports
1 x 1 Gbps SFP Ethernet Router Port
1 x USB 3.0 reserved for future
LEDs: Data Ports: Speed / Link / Activity, PoE
SFP Data Port: Link / Activity
Power: Max. Power Consumption: 16W (Excludes PoE Output)
Power Method: 24V, 2.5A Power Adapter (Included)
Power Supply: External AC Power Adapter, 60W (24V, 2.5A)
Supported Voltage Range: 100-240V AC, 50/60 Hz Universal Adapter 30-16V
