Specifications: Interfaces
Telephone Interfaces Two (2) FXS ports
Network Interfaces One (1) 10/100Mbps auto-sensing ethernet ports (RJ45)
LED Indicators POWER, INTERNET, PHONE1, PHONE2
Factory Reset Button Yes
Voice, Fax, Modem
Telephony Features Caller ID display or block, call waiting, flash, blind or attended transfer, forward,
hold, do not disturb, 3-way conference
Voice Codecs G.711 with Annex I (PLC) and Annex II (VAD/CNG), G.723.1, G.729A/B, G.726, iLBC,
dynamic jitter buffer, advanced line echo cancellation
Fax Over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax
Pass-through
Short/Long Haul Ring Load 2 REN: Up to 1km on 24 AWG
Caller ID Bellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CID
Disconnect Methods Busy Tone, Polarity Reversal/Wink, Loop Current
Signaling
Netwo...
Specifications: Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
Device Interface:
1 x Gigabit port
1 x PoE+ Gigabit port
4-pin removable terminal block
LED indicators
DIN-Rail mount
Wall mount
Grounding point
Data Transfer:
RateEthernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit: 2000 Mbps (full duplex)
Power:
Input: 48 – 56 V DC
Compatible power supply: TI-S12048 (sold separately)
Consumption: Max. 72 Watts
PoE budget: 60 Watts
Pin 1,2 for power+ and pin 3,6 for power- (mode A)
Pin 4,5 for power+ and pin 7,8 for power- (mode B)
