Specifications: Audio: Yes
Chipset ID: STDP4320
Converter Type: MST Hub
Output Signal: HDMI
Ports: 2
Maximum Digital Resolutions: 3840x2160 @ 30 Hz
Supported Resolutions:
Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.
Average resolution bandwidth allocation
1920 x 1080 (High-definition 1080p) @60 Hz - 22%
1920 x 1200 @60hz - 30%
2560 x 1440 @60hz - 35%
2560 x 1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30 Hz - 38%
Note: Exceeding 100% will reduce functionality.
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Specifications: 1.Model: WL-UG7501H
2.Chip: DisplayLink DL7400
3.Connection to Host: USB-C/A
4.Video Ports: 4 x HDMI
5.Product Size: 11.3 x 9.9 x 1.5cm/4.5x3.9x0.6in (L x W x H) 6.Cable Length: 23cm/9.1in
7.Product Weight: 206g/7.3oz
Features: - 4 x HDMI ports support quad 4K@60Hz.
- 1 x USB-C/A 2-in-1 cable, easily connect to the host.
- 1 x USB-C 100W PD in charging to the laptop.
Specifications: 6 inch USB-C to VGA, USB 3.0, USB-C Power Pass-Through Multiport Dock
The multiport dock from PI Manufacturing allows you to expand the ports and display connectivity options for your desktop, laptop, or other USB-C enabled device. The dock include a VGA port for outputting to a VGA display with support for resolutions up to 1920x1200 or 1080p, an USB 3.0 port for plugging in printers, external hard drives, thumb drives, and more, and a USB-C power delivery pass-through port for charging via your laptop's power adapter while the dock is in use.
Compact / Portable Size
The USB-C dock is perfect for on-the-go travel and comes with all the ports necessary for most applications.
Display Resolution
Support for resolutions up to 1920 x 12...
Specifications: 1.Model: WL-UG7501D
2.Chip: DisplayLink DL7400
3.Connection to Host: USB-C/A
4.Video Ports: 4 x DP
5.Product Size: 11.3 x 9.9 x 1.5cm/4.5x3.9x0.6in (L x W x H) 6.Cable Length: 23cm/9.1in
7.Product Weight: 206g/7.3oz
Features: - 4 x DP ports support dual 8K@60Hz and quad 4K@120Hz.
- 1 x USB-C/A 2-in-1 cable, easily connect to the host.
- 1 x USB-C 100W PD in charging to the laptop.
Specifications: Easy to Add Displays:
Extend video to a second monitor, duplicate the same video on both monitors or make the second monitor your primary display
Ideal for multitasking, viewing spreadsheet data, editing documents, giving presentations, watching movies and playing video games
Add up to 6 adapters for a total of 7 displays (Windows)
Add up to 4 adapters for a total of 5 displays (Mac)
No need to reboot system after adding or removing a monitor
Plug and play - no external power supply needed
Vibrant, Superior Video Quality:
Supports high-definition video resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Features 128 MB DDR SDRAM of memory
Resumes automatically from hibernation and suspend modes
Broad Compatibility:
Works with 32- and 64-bit Windows 2000 and later
Works with 32- and 64-bit Intel Mac OS...
Specifications: CE Approval: Yes
Connectors: Inputs on integrated cable (to server): VGA: HD15 M; USB: USB Type A M; Outputs (to laptop): Mini USB Type B F (USB 2.0), with detachable USB Mini Type B male to USB Type A male cable
Laptop Requirements: PC running Windows 2000, Windows XP, or Windows Vista or Mac OS X 10.5 (Leopard) or higher (Intel processor only); (1) available high-speed USB port (100-mA current); 20 Megabytes available disk space for install; 24-bit color display
Power: From the server or laptop USB interface with a maximum of 500 mA at 5 VDC
Resolutions (Maximum): 1920 x 1200 at 60 Hz or 1600 x 1200 at 75 Hz
RoHS: Yes
Server Requirements: (1) USB port (full speed) for keyboard/mouse (500-mA current); analog VGA graphics output (analog DVI can be used with adapter); OS supporting absolute U...
Specifications: USB-C to VGA mini dock adds VGA, USB-A and USB-C PD ports to your laptop, MacBook, Chromebook or other compatible device.
Transmits video signals from sources supporting USB DisplayPort Alt Mode
Delivers HD picture quality at resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Supports USB 3.1 Gen 1 speeds up to 5 Gbps to ensure fast data transfers
Reversible USB-C plug connects in either direction for immediate no-fuss use
Easy installation with plug-and-play operation-no software required
Connectors:
Side A - Connector 1: USB-C (MALE)
Side B - Connector 1: VGA (FEMALE)
Side B - Connector 2: USB 3.0 A (FEMALE)
Side B - Connector 3: USB-C (FEMALE)
Type: 6-in-1 USB 3.1 Gen 1 Type-C Hub Docking Station
Changer Type: USB to Dual USB-A, HDMI 4K, VGA, USB PD Fast-Charging 60 W, and Detachable QI Wireless Charger
Color: Black
Specifications: A 6-in-1 USB-C Hub with wireless charging up to 10W for efficient, hassle-free charging on a Qi pad. For fast charging, 60W USB PD charging may also be used.
Wireless charging pad on the station is detachable, you can take it on the go and use it independently. Simply setting down your phone on the station and charge wirelessly. Compatible with iPhone Xs MAX/XR/XS/X/8/8 Plus, Galaxy Note 9/S9/S9 Plus/Note 8/S8, All Qi-Enabled Phones.
Complete with a 4k HDMI port, 1080P VGA Port, 1 USB A 3.0 ports, and USB A 3.0 port this hub is the ultimate tool with every feature you could want, and more!
HDMI with audio support allows for the transmission of high ...
Specifications: Chipset ID: MCT - Trigger 1+
Memory: 16MB SDRAM
USB Pass-Through: No
General Specifications: This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset.
Supported Resolutions: Standard (1600 x 1200, 1400 x 1050, 1280 x 1024, 1280 x 960, 1152 x 864, 1024 x 768, 800 x 600) / Widescreen (1680 x 1050, 1440 x 900, 1280 x 800, 1280 x 768, 1152 x 864, 800 x 600)
Connector A: 1 x USB Type-A (4 pin) USB 2.0 Male Input
OS Compatibility: Windows 10 (32/64) / Windows 8 / 8.1 (32/64) / Windows 7(32/64) / Windows Vista (32/64) / Windows XP (32/64)
System and Cable Requirements: One available USB 2.0 port
Specifications: USB 3.1 Type-C to VGA adapter for connecting a USB-C enabled smartphone, tablet or computer to an VGA-equipped monitor or display Compatible with analog VGA-enabled TVs/Monitors/Projectors for both video transfer This USB-C to VGA adapter Only Compatible with device with DisplayPort Alt Mode, Windows computers may need updated USB-C or Thunderbolt 3 drivers from the manufacturer. Video resolution up to 1920x1080p@60Hz for compatibility with most displays, monitors and projectors compatible with the following PC, Laptop: iMac 2017 / iMac Pro 2017 MacBook Pro 2017 & 2016 MacBook 2016 & 2015 New Chromebook Pixel Dell XPS 15 & 13 & 12 Yoga 920 Yoga 910, For Yoga 910 users, please ONLY plug the adapter into the White USB-C female port. Yoga 900(Yoga 4 Pro) HP Spectre x360 13 & 15 inch Asus Zen AIO All in One PC Surface Book 2 More Thunde...
Changer Type: USB Type-C to Type-A, VGA & Type-C Adapter
Color: White
Specifications: Connect A: USB 3.1 Type-C Male
Connect B: USB 3.0 Type-A Female / VGA (HD15) Female / Type-C Female
Compatible Devices for USB 3.1 Type-C with DP Alt Mode or Thunderbolt 3 (not a full list)
PC:
MacBook 2015 and newer/ MacBook Pro 2016 and newer/ iMac 2017 and newer/ iMac Pro 2017 and newer
MacBook Air 2018/ iPad Pro 2018 / New Mac Mini
Dell XSP 15/13
ASUS T303ua/ ZenBook 3
Lenovo YOGA900/910/920 / Lenovo Thinkpad X1 Carbon 5th
Chromebook Pixel 2
HP EliteBook Folio G1/ Spectre 13 X360
Huawei Matebook
And more...
Smartphones:
Huawei Mate 10
Samsung Galaxy S8/S8+/S9 / Samsung Galaxy Note8/9
Microsoft Lumia 950 / LG G5 / V20 / V30
And more...
