Specifications: The USB-C to VGA adapter allows devices that support DisplayPort Alternate Mode to output onto a separate display at resolutions up to 1920x1200 or 1080p.
DisplayPort Alternate Mode leverages the features provided by USB 3.1 to allow devices to output onto a separate display. (Note that resolution and refresh rates are dependent on the source device). It does this by repurposing the wires in USB 3.1 (USB 3.1 has 4 lanes / 8 wires).
Note that your source device must have DisplayPort Alternate Mode. Such devices include the 12" Apple Macbook , Google Chromebook Pixel (certain models), along with several other devices. If you plug in a non supported device, it will not damage the device, but no video will be displayed.
Compact / Portable Si...
Specifications: 6 inch USB-C to VGA, USB 3.0, USB-C Power Pass-Through Multiport Dock
The multiport dock from PI Manufacturing allows you to expand the ports and display connectivity options for your desktop, laptop, or other USB-C enabled device. The dock include a VGA port for outputting to a VGA display with support for resolutions up to 1920x1200 or 1080p, an USB 3.0 port for plugging in printers, external hard drives, thumb drives, and more, and a USB-C power delivery pass-through port for charging via your laptop's power adapter while the dock is in use.
Compact / Portable Size
The USB-C dock is perfect for on-the-go travel and comes with all the ports necessary for most applications.
Display Resolution
Support for resolutions up to 1920 x 12...
Specifications: Audio Specifications: HDMI and mDP output - 7.1 surround sound
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 x 2160
Supported Resolutions:
HDMI and mDP output: 3840 x 2160, 2560 x 1600, 1920 x 1200, 1920 x 1080, 1280 x 720
DVI and VGA output: 1920 x 1200, 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported
Humidity: 40%-50%RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -10°C to 80°C (14°F to 176°F)
Specifications: System Requirements:
Computer with USB-C port that supports USB DisplayPort Alternate Mode
DisplayPort, Mini DisplayPort, VGA, DVI or HDMI external display
Ethernet network
Thunderbolt 3: Yes
Package Contents: U442-DOCK1 USB 3.1 Gen 1 USB-C Docking Station
Owner’s manual
Specifications: Active or Passive Adapter: Active
Adapter Style: Adapters
AV Input: USB Type-C
AV Output: HDMI / DVI-D / VGA / Mini-DisplayPort
Chipset ID:
Parade - PS176
VIA/VLI - VL102
ITE -IT6516
Audio Specifications: HDMI or mDP output: 7.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 @ 60Hz
Maximum Digital Resolutions:
4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz (HDMI)
4096 X 2160 @ 60Hz (mDP)
Supported Resolutions:
Maximum HDMI output: 4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz
Maximum mDP output: 4096 X 2160 @ 60Hz
Maximum DVI and VGA output: 1920 x 1200 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision: HDMI 2.0 / DisplayPort 1.2
Wide Screen Supported: Yes
Note: On...
Specifications: USB-C to VGA mini dock adds VGA, USB-A and USB-C PD ports to your laptop, MacBook, Chromebook or other compatible device.
Transmits video signals from sources supporting USB DisplayPort Alt Mode
Delivers HD picture quality at resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Supports USB 3.1 Gen 1 speeds up to 5 Gbps to ensure fast data transfers
Reversible USB-C plug connects in either direction for immediate no-fuss use
Easy installation with plug-and-play operation-no software required
Connectors:
Side A - Connector 1: USB-C (MALE)
Side B - Connector 1: VGA (FEMALE)
Side B - Connector 2: USB 3.0 A (FEMALE)
Side B - Connector 3: USB-C (FEMALE)
