Specifications: Resolution: 3840 x 2160 at 30Hz (Dual Display)
Resolution: 3840 x 2160 at 60Hz (Single Display)
Output: Requires 5V, 2A external power over Micro-B USB port
DisplayPort 1.2a compliant
Link Rate: HBR2/HBR/RBR
Bandwidth: 5.4Gbps max.
Support SST and MST (when both host and monitor support)
Support 7.1 sound channel; max. sampling size 192KHz
Rating: Temp 80°C, Voltage 30V
Conductor Resistance: At 20°C max 30AWG: 376.95 O/KM
Insulation Resistance: 10M -KM min at 20°C DC 500V (EIA-364-21)
Dielectric Strength: AC 500V/1 minute no breakdown (EIA-364-20)
Impedance: Pairs (differential mode) 100±50HMS
Attenuation (max.): 5.02dB@100~450MHz; 7.695dB@1GHz; 12.595dB@2GHz; 17.495dB@3GHz; 22.395dB@4GHz; 27.295dB@5GHz; 32.195dB@6GHz; 37.095dB@7GHz
Return...
Type: Conference Table Connectivity Box for A/V - 4K
Color: Black
Specifications: Input Voltage: 100 ~ 240 AC
Output Current: 2A
Output Voltage: 12 DC
Plug Type: N
Power Consumption (In Watts): 24W
Power Source: AC Adapter Included
Aspect Ratio: Wide (16:9)
Maximum Analog Resolutions: 1920 x 1200 60Hz
Maximum Cable Length: 50 ft [15.2 m]
Maximum Digital Resolutions: 3840x2160 (4K) 30Hz
Supported Resolutions:
3840x2160 (4K) 30Hz (HDMI and DP Inputs Only)
2560x1600 60Hz (HDMI and DP Inputs Only)
1920x1200 60Hz (Maximum VGA Input)
1920x1080 (1080p) 60Hz
1280x720 (720p) 60Hz
**Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Video Revision: HDMI 1.4 / DisplayPort: 1.2
Wide Screen Supported: Yes
Note:
VGA (Input) to HDMI (Output) - HDMI Output Port is Active
DisplayPort (Input) to HDMI (Output) - ...
