Specification: OVERVIEW
Display Style: Extender
Model Type: VGA
Cable Types: CAT5/CAT5E
PHYSICAL
Included Mounting Accessories: Yes
ENVIRONMENTAL
Operating Temperature Range: 0 to 40 C (32 to 104 F)
Storage Temperature Range: -20 to 60 C (-4 to 140 F)
Relative Humidity: 20 to 90%
CONNECTIONS
Connector A: HDMI (FEMALE) (X4)
Connector B: RJ45 (FEMALE) (X4)
Feature: Tripp Lite's B126-4X4 HDMI over Cat5/6 Matrix Splitter Switch and Transmitter Unit allows you to share high-definition video and audio from four HDMI-enabled digital video components (e.g., DVR, Cable Box, Blu-Ray, HD gaming consoles, etc.) to four different monitors. When used with Tripp Lite Active HDMI receivers, it can extend
Distance: up to 200 ft. at 1024 x 768 (60Hz)
up to 150 ft. at 1920 x 1080 (60Hz)
Color: Black
LED Indicator: The Green RJ45 LED on the local unit illuminates to indicate it is connected to and receiving power from the source. The Orange RJ45 LED on the local unit does not illuminate. The Green RJ45 LED on the remote unit illuminates to indicate it is receiving power from the external power supply. The Orange RJ45 LED on the remote unit illuminates to indicate it is connected to the local unit and receiving a signal from the source.
Resolution Support: Up to 4K@35m (Cat 5e/6) / 40m (Cat 6a); 1080p@60m (Cat 5e/6) / 70m (Cat 6a)
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Power Supply: VE802R
Connectors: 1 x DC Jack (Black) with locking
Consumption: DC 5V, 4W
VE802T
Connectors: 1 x DC Jack (Black) with locking
Consumption: DC 5V, 3.6W
Feature: The VE802 HDMI HDBaseT-Lite Extender extends an HDBaseT signal up to 70m from the HDBaseT source using one Cat 5e/6/6a cable. VE802 supports RS-232 and IR signaling passthrough, allowing you to control the HDMI source device from the remote unit (VE802R) while also granting access to the HDMI display device from the local unit (VE802T). IR signals can also be extended in both directions. The VE802 features Power over HDBaseT (POH) which can send power over Cat 5e/6/6a cable without an add...
