UPS Accessories

• Type: Service Bypass Panel
• Specifications: Output: Nominal Output Voltage: 100V, 120V Maximum Total Current Draw per Phase: 30A Output Connections: (6) NEMA 5-15R, (2) NEMA 5-20R Overload Protection: Yes Cord Length: 10 ft (3.05 meters) Input: Nominal Input Voltage: 100V, 120V Input Frequency: 50/60 Hz Input Connections: NEMA L5-30P Cord Length: 10 feet (3.05 meters) Number of Power Cords: 1 Maximum Line Current per phase: 24A Maximum Input Current per phase: 24A Load Capacity: 3000 VA Load Power Factor Range: 0 to 1 Color: Black
• Dimensions: Maximum: 25.5" x 17.0" x 3.5"
• Weight: 30.00 lbs.
• Model #: SBP3000RM2U

• Type: Battery
• Model #: SRT96RMBP

• Type: Battery
• Specifications: Battery Volt-Amp-Hour Capacity: 372 Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof Battery mounting: Stand alone battery stack Expected Battery Life (years): 4 - 6 Included Battery Modules: 2
• Weight: 30.00 lbs.
• Model #: BR24BPG

• Type: External Battery Pack
• Specifications: INPUT: UPS Input Cord Length (ft.): 3 Input Phase: Single-Phase OUTPUT: Overload Protection: 50A DC output fuse BATTERY: Expandable Battery Runtime: Includes a second input/output connector to daisy-chain multiple battery packs Expandable Runtime: Yes DC System Voltage (VDC): 192 UPS Connection: Detachable cable with UPS specific DC connector (90 cm length, 8 gauge) Typical Battery Lifespan: 4-6 years typical (North America)
• Dimensions: 5.25" x 17.50" x 28.00"
• Weight: 174.00 lbs.
• Model #: BP192V12RT3US

• Type: Battery
• Compatibility: Compatible with these UPS Systems - OMNIVS1500XL, OMNIVSINT1500XL, SMART750RMXL2U, SMART750XLA, SU750RTXL2U, SU750RTXLCD2U, SU750XL, SU1000RTXL2UA, SU1000RTXLCD2U, SU1000XLA, SU1000XLCD, SUINT1000RTXL2UA and other Tripp Lite UPS systems that specify the use of this battery pack.
• Specifications: DC System Voltage (VDC): 24 UPS Connection : Attached cable with red/black 75 amp male DC connector
• Dimensions: 3.50" x 17.50" x 14.00" (H x W x D)
• Model #: BP24V28-2U

• Type: Battery
• Specifications: OUTPUT Overload protection: 50A DC output fuse INPUT Input cord length: 36.00", 8 AWG, 3 conductor BATTERY Expandable battery runtime: Includes a second input/output connector to daisy-chain multiple battery packs DC system voltage: 192V DC Connects to UPS via: Detachable cable with UPS specific DC connector (90 cm length, 8 gauge)
• Dimensions: 5.25" x 17.50" x 28.00"
• Weight: 174.00 lbs.
• Model #: BP192V12-3U

• Type: Battery
• Weight: 7
• Model #: BAT-APC-BN700MC

OUT OF STOCK

• Type: UPS Battery Pack
• Compatibility: Tripp Lite UPS:
  SMART1000RMXL2U SMART1200XLHG SMART1500RMXL2UA SMART1500RMXLN SMART1500XL SMX1200XLHG SMX1500XLRT2U
• Specifications: Battery Life:4 Year to 6 Year typical (North America) Output Voltage:36 V DC
• Weight: 68.90 lb
• Model #: BP36V27-2US
