Digital Video Capture Resolution: Graphics Modes (Live): 4K UHD
Maximum Video Resolution (Live): 3840 x 2160
Maximum Frame Rate: 60 fps
Specification: Interfaces/Ports
HDMI In
HDMI Out
Network (RJ-45)
USB
Number of Network (RJ-45) Ports: 1
Number of HDMI Inputs: 1
Number of HDMI Outputs: 2
Technical Information
Features: Noise Reduction
Room Size: Medium
Camera: 12MP camera
30 frames per second
1/2.3’’ CMOS
5x digital zoom
f/2.5 aperture
120° horizontal field of view
95° vertical field of view
Auto framing (face detect)
Speaker tracking
Auto brightness and white balance
Fixed focus lens
Automatic rotation of the image when the video bar unit is mounted upside down
Frames camera mode for individual participant framing
Digital Video Capture Resolution: Video Standards:
H.263, H.264, AV1
Video Inputs:
1x HDMI input supports formats up to maximum 3840 x 2160 at 30 fps, including 1920 x 1080 at 60 fps
1x USB-C input supports formats up to maximum 3840 x 2160 at 30 fps, including 1920 x 1080 at 60 fps
Consumer Electronics Control (CEC) 2.0
Video Outputs:
2x HDMI outputs supporting formats up to 3840 x 2160 at 60 fps
Live video resolutions (encode and decod...
Specification: Ports
2 USB Type-A 5Gbps signaling rate; 1 HDMI-in 2.0; 1 line in; 1 line out; 2 HDMI-out 2.0 (video); 1 PoE+ 802.3at-class 4 LAN RJ-45; 1 LLN RJ-45; 1 USB Type-C® 5Gbps signaling rate (with DisplayPort™ Alt Mode for video input)
Security management
802.1x support
Special features
Speaker framing; People framing; Group framing; Presenter tracking; DirectorAI perimeter supported
