Specifications: Includes height-adjustment column, desk clamp, LCD pivot, worksurface/keyboard, one (1) USB extension cable, one (1) cable wrap
NOTE: Extra-long cables are required to span between standing and sitting heights
Optimized for desks that are 30"-36" deep (76-91 cm): on desks shorter than 30", worksurface will extend beyond desktop edge; on desks deeper than 36", worksurface will not extend to desktop edge
Worksurface Dimensions: 29.5" x 21.8" (75 x 55.4 cm)
Weight Capacity: Maximum total load on height-adjustment assembly = 16 lbs (7.3 kg). LCD weight = 3-13 lbs (1.3-5.9 kg); worksurface = 5 lbs (2.3 kg)
LCD and keyboard adjust 18" (46 cm) in tandem; LCD adjusts 5" (13 cm) independently; maximum LCD height adjustment = 23" (58 cm)
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 ...
Specifications: Includes height-adjustment column, desk clamp, crossbar, two (2) LCD pivots, worksurface/keyboard, one (1) USB extension cable, two (2) cable wraps
NOTE: Extra-long cables are required to span between standing and sitting heights
Optimized for desks that are 30"-36" deep (76-91 cm): on desks shorter than 30", worksurface will extend beyond desktop edge; on desks deeper than 36", worksurface will not extend to desktop edge
Worksurface Dimensions: 29.5" x 21.8" (75 x 55.4 cm)
Maximum outside width of display is 24.5" (62 cm) when display is 2" (5 cm) thick. Accommodates most displays with screen-size up to 24" as well as some displays with screens as large as 26". Actual allowable width of displays will vary depending on display thickness
Weight Capacity: Maximum total load on height-adjustment assembly = 25 ...
Specifications: Includes height-adjustment column, desk clamp, LCD pivot, worksurface, large keyboard tray
NOTE: Extra-long cables may be required to span between standing and sitting heights
Weight Capacity: Maximum total load on height-adjustment assembly = 29 lbs (13.2 kg). LCD weight = 16-28 lbs (7.3-12.7 kg), worksurface = 5 lbs (2.3 kg), keyboard tray = 5 lbs (2.3 kg). For proper operation the total weight of components when added together should not exceed 29 lbs (13.2 kg)
Lift Range: LCD and keyboard adjust 18" (46 cm) in tandem; LCD adjusts 4.8" (12.2 cm) independently; maximum LCD height adjustment = 22.8" (58 cm). The worksurface restricts the vertical travel range of the LCD lift pivot; height adjustment of LCD without worksurface is 5" (13 cm)
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern = 100 ...
