Networking

• Type: HDBaseT Extender
• Color: Black
• Specifications: Audio: Yes Cabling: Cat 5e UTP or better Daisy-Chain: No Ports: 1 Rack-Mountable: Yes Audio Specifications: 7.1 Surround Sound Max Distance: 70 m / 230 ft Maximum Cable Length: 229.6 ft [70 m] Maximum Digital Resolutions: 4096 x 2160 (4K) @ 30 Hz Wide Screen Supported: Yes Local Unit Connectors: 2 - HDMI (19 pin) Female Input 1 - DisplayPort (20 pin) Female Input 1 - 3.5 mm Mini-Jack (3 Position) Female Input 1 - VGA (15 pin, High Density D-Sub) Female Input 1 - HDMI (19 pin) Female Output 2 - IrDA (Infrared, SIR/FIR) Female 1 - RJ-45 Female Output Remote Unit Connectors: 1 - RJ-45 Female Input 1 - HDMI (19 pin) Female Output LED Indicators: 4 - port selection LEDs 2 - status LEDs (local) 1 - Status LED (remote) Center Tip Polarity: Positive Input Current: 0.6 A Input Voltage: 100 ~ 240 AC Out...
• Model #: STDHVHDBT

OUT OF STOCK

• Type: Converter
• Specifications: 10/100/1000BASE-T (RJ-45) [100 m/328 ft.] to 1000BASE-SX 850nm multimode (SC) [62.5/125 µm fiber: 220 m/722 ft.] Link Budget: 7.0 dB [50/125 µm fiber: 550 m/1804 ft.] Standards: IEEE 802.3 Max Frame Size: untagged: 1632 bytes / tagged: 1628 bytes Status LEDs: PWR (Power): (below RJ-45) ON = Lit for normal operation FX-Link/Act (Fiber Link/Activity): (Upper Left on RJ-45) ON = Link; Flashing = Activity TX-Link/Act (Copper Link/Activity): (Upper Right on RJ-45) ON = Link; Flashing = Activity Power Consumption: 3.15 Watts Sources: Unit accepts 5 VDC to 28 VDC Wall Mount AC adapter: 12 VDC 400mA Environment Storage: -15 to +65 °C Operating: 0°C to 50°C Altitude: 0 – 10,000 feet Humidity: 5% to 95% (non-condensing) Compliance Safety: Wall Mount Power Supply, UL Listed, C-UL Listed (Canada) FCC Class A, CISPR22/EN55022...
• Model #: M/GE-PSW-SX-01-NA

OUT OF STOCK

• Model #: 26443420974337
