Standards: IEEE 802.3x Flow Control
IEEE 802.3ad Link Aggregation Control Protocol
IEEE 802.1X Network Login
IEEE 802.1Q VLAN tagging
IEEE 802.1s Multiple Spanning Trees
IEEE 802.1AB Link Layer Discovery Protocol
IEEE 802.1Q VLANs
IEEE 802.1p Priority
Primary Ports: 24 RJ-45 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-T)
1 RJ-45 serial console port
2 Dual Personality Ports each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an open mini-GBIC slot (for use with mini-GBIC transceivers)
Standards: IEEE 802.1w Rapid Convergence Spanning Tree
IEEE 802.1AB Link Layer Discovery Protocol
IEEE 802.3af Power over Ethernet
IEEE 802.1p Priority
IEEE 802.3x Flow Control
IEEE 802.1D Spanning Tree
IEEE 802.3ad Link Aggregation Control Protocol
IEEE 802.1X Network Login
IEEE 802.1Q GVRP
Primary Ports: 24 RJ-45 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-T)
1 RS-232C DB-9 console port
2 Dual Personality Ports each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an open mini-GBIC slot (for use with mini-GBIC transceivers)
Standards: IEEE 802.1w Rapid Convergence Spanning Tree
IEEE 802.1AB Link Layer Discovery Protocol
IEEE 802.3af Power over Ethernet
IEEE 802.1p Priority
IEEE 802.3x Flow Control
IEEE 802.1D Spanning Tree
IEEE 802.3ad Link Aggregation Control Protocol
IEEE 802.1X Network Login
IEEE 802.1Q GVRP
Primary Ports: 48 RJ-45 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-T)
1 RS-232C DB-9 console port
2 Dual Personality Ports each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an open mini-GBIC slot (for use with mini-GBIC transceivers)
Features: Radios:
Single 5-GHz radio
Radio implements 2x2 MIMO with two spatial streams, providing up to 300 Mbps data rate
Maximum aggregate transmit power per radio: up to 25 dBm
Dual receiver chain maximal ratio combining (MRc) for improved receiver performance
RF Management:
RF interference detection and avoidance
Antenna:
Built in antenna
Frequency range and max gain:
- 5.470 to 5.700 GHz: >11.5 dBi
- 5.700 to 5.900 GHz: 13 dBi
Beamwidth:
- e-plane: 13 degrees
- H-plane: 55 degrees
Performance Data Transfer Rate: 300 Mbps
Ports / Connectors:
1 x GbE RJ-45 autosensing
1 x USB console
Specifications: No. of Ports: 12
Pass Through Data Rates 10/100/1000 Mbps
PoE Output:
Pin Assignment and Polarity:
Data Pairs 1/2 (-) and 3/6 (+)
Spare Pairs 7/8 (-) and 4/5 (+)
Output Power Voltage: 54-57V DC
User Port Power: 72W Typ.
Aggregate Power: 1000W
Input Power Requirements:
AC Input Voltage: 100 to 240V AC
DC Input: 57V (RPS or another 9500G midspan)
AC Input Current: 450W Units: 5.5A @ 110V AC; 2.75A @ 220V AC
1000W Units: 12A @ 110V AC; 6A @ 220V AC
AC Frequency: 50 to 60 Hz
Management PowerView Pro included
Indicators:
System Indicator: AC Power (Green)
User Indicator: Channel Power (Green / Orange)
Connectors:
PoE ports and management port: Shielded RJ-45, EIA 568A and 568B
Console Port: USB Connector Type B
DC Connector: DC Block Terminal
RPS Com Connector: HD-D-sub-15
Standard: C-Tick, EN 60950, NOM, UL 60950, CB, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6,
FCC Part 15, MIC, AS / NZS 3548, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, ANATEL, cTUVus,
CAN / CSA C22.2 No. 60950, VCCI Class A, EN 61000-3, EN 55024, EN 55032 Class A, CISPR 32 Class
A
Ports: 1 x Console - RJ-45
1 x USB
1 x 1000Base-T (management)
2 x 10GBase-X - SFP+
Power Input: Power Device: External power adapter
Voltage Required: AC 120/230V (50/60 Hz)
Power Consumption Operational: 120 Watts
Power Provided: 400 Watts
