Specifications: Interface:
"PoE (Power + Data)" Input Port : 1 x RJ-45 10/100/1000Base-T
"Data" Out Port: 1 x RJ-45 10/100/1000Base-T
DC Out Plug Connector: 1 removable 4-Pin terminal block
LED Indicator:
System: Power Ready x 1 (Green)
Network Cable:
10/100/1000Base-T: 4-Pair UTP Cat. 5, 5e, 6
Distance up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate: 10/100/1000 Mbps (vary on Ethernet device attached)
DIP Switch: 12V DC / 24V DC output voltage
Power Input: 802.3at PoE 48~56V DC
Power Output: 12V / 24V DC, max 2A (adjustable)
Enclosure: IP30 metal case
Installation: DIN rail kit and wall mount ear
ESD / EFT Protection: 6 KV DC
PoE Standard: IEEE 802.3at High Power over Ethernet
Number of devices that can be powered: 1 or 2 (Vary on device's power requirement; DC1 + DC2 cannot be over 25 watts.)
...
Specifications: Standards and Protocols: IEEE Std 802.3, 802.3ab, 802.3bz, 82.3an
Power Supply: 3.3V
Max. Cable Length:
- 100BASE-TX: UTP cat .5 or above (max. 100m)
- 1000BASE-T/2.5GBASE-T/5GBASE-T: UTP cat.5e or above (max. 100m)
- 10GBASE-T: UTP cat.6a or above (max. 30m)
Data Rate: 10.3 Gbps
Port Type: 1 x 10G RJ45 Port
Safety & Emission: FCC, CE, RoHS
Environment:
- Operating Temperature: 0 - 70 °C (32 - 158 °F)
- Storage Temperature: -40 - 85 °C (-40 - 185 °F)
Features: Support 10GBASE-T, 5GBASE-T, 2.5GBASE-T, 1000BASE-T, and 100BASE-TX
Transmit data up to 30m* at 10 Gbps (UTP cat.6a or above)
Support DDM (Temperature and Voltage)
Hot-Pluggable SFP+ Footprint Features
Support TX Disable function
Commercial Product Operating Temperature Range: 0-70°C
Fully Metallic Enclosure for Low EMI
