Specifications: Interface: Input Port:
1 x RJ-45 STP
PoE (Data + Power) In
Output Port
1 x RJ-45 STP
Data Out
DC Socket
DC Out
DIP-Switch
12V DC / 19V DC / 24V DC output voltage
LED Indicator:
System: Power x 1 (Green)
Network Cable:
Ultra PoE (60W): 10/100/1000Base-T: 4-Pair UTP Cat. 5e, 6 up to 100m (328 ft.)
802.3af/at PoE (15W / 30W): 10/100/1000Base-T: 2-Pair UTP Cat. 3, 5, 5e, 6 up to 100m (328 ft.)
Data Rate: 10/100/1000 Mbps
Power Requirements: 52 ~ 56V DC
Power Consumption: 50 watts (maximum)
Operating Temperature: 0 ~ 50 degrees C
Storage Temperature: -10 ~ 70 degrees C
Humidity: 5 ~ 95% (Non-condensing)
PoE Standard: IEEE 802.3at Power over Ethernet Plus
Power Output: DC 12V / 19V / 24V by DIP switch control
DC Plug connectors (Diameter):
2 external female plug cables:
5.5 / 2.5mm to 5.5 / 2.5mm
5.5 ...
Specifications: Industry Standards:
IEEE 802.3af PoE, IEEE 802.3at PoE+
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
Ports: 4
Maximum Cable Length: 328 ft [100 m]
Maximum Data Transfer Rate: 2 Gbps (Full-Duplex)
MTBF: 50,000 Hours
Power Output: 52V DC at 30.8W (PoE+)
Connector Type(s): 8 - RJ-45 Female
Enclosure Type: Steel
LED Indicators: 1-Power, 4-PoE In-Use
Center Tip Polarity: Positive
Input Current: 2-1 A
Input Voltage: 100 ~ 240 AC
Output Current: 2.31 A
Output Voltage: 52 DC
Plug Type: M
Power Consumption: 120 W Max
Power Source: AC Adapter Included
Included in Package:
1 - 4 Port Gigabit PoE+ Injector
1 - Universal Power Adapter
3 - Power Cords (NA/UK/EU)
1 - Instruction Manual
