Features: • Industrial power supply with integrated DIN-rail mount
• Provides up to 240 Watts of power (48 V, 5 A)
• Built-in active PFC (PF > 0.93)
• Short circuit/overload/over voltage/over temperature protection
• High efficiency (94%) design
• UL 508 approved
• 100 % full load burn-in test
• Extreme -25 to 70 °C (-13 to
Specifications: Standards:
IEEE 802.3af (Power over Ethernet)
IEEE 802.3at (High-Power PoE+ Power over Ethernet)
IEEE 802.3 (10Base-T Ethernet)
IEEE 802.3ab (Gigabit Ethernet)
IEEE 802.3u (100Base-TX Fast Ethernet)
General:
Ports:
- One RJ45 10/100/1000 Mbps input port for 48V IEEE 802.3af/at-compliant signal
- One RJ45 10/100/1000 Mbps PoE output port
Certifications: FCC Class B, CE
Power:
Max PD output power: 25W max
Max Power consumption: 4W
Input power: IEEE 802.3af/at compliant PSE
PoE Pinout Input:
- IEEE Alternative A (pairs 1/2 and 3/6)
- IEEE Alternative B (pairs 4/5 and 7/8)
PoE Pinout Output:
- IEEE Alternative A (pairs 1/2 and 3/6)
