Quick View
StarTech.com 1 Port Gigabit PoE+ Network Extender, 802.3at and 802.3afType: PoE+ ExtenderColor: BlackSpecifications: Hardware
Port: 1
Industry Standards:
IEEE 802.3af PoE, IEEE 802.3at PoE+
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
Performance
Auto MDIX: Yes
Auto-Negotiation: Yes
Compatible Networks: 10/100/1000 Mbps
Flow Control: Half-duplex back-pressure , IEEE 802.3x pause frame for full-duplex
Full Duplex Support: Yes
Jumbo Frame Support: No
Maximum Cable Length: 328 ft. [100m]
Maximum Data Transfer Rate: 2 Gbps (Full-Duplex)
MTBF: 50,000 Hours
Power Output: One extender-24W
Power Output: Two extender daisy chain-20W
Power Output: Three extender daisy chain-16W
Power Output: Four extender daisy chain-12W
Surge Protection:
EN61000-4-2 (ESD)-2kV
EN61000-4-5 (Surge)-2kV
Switching Architecture: Store-and-Forward
Connector Type(s): 2-RJ-45 Female
Enclosure Type: Steel
Indicators
LED Indi...Model #: POEEXT1GAT
Quick View
PLANET IPOE-171-95W Industrial Single-Port 10/100/1000 Mbps 802.3bt PoE Injector (95 Watts, -40~75 degrees C, 12~48V DC)Type: PoE InjectorSpecifications: Interface:
Input Port:
1 x RJ45 STP
Data In
Output Port:
1 x RJ45 STP
PoE (Data + Power) Out
Input power terminal block: 1
Network Cable:
Twisted-pair cable up to 100 meters (328 ft.)
10BASE-T: 4-pair UTP Cat. 3, 4, 5, 5e, 6
100BASE-TX: 4-pair UTP Cat. 5, 5e, 6
1000BASE-T: 4-pair UTP Cat. 5e, 6
Data Rate: 10/100/1000 Mbps
Dimensions: 1.26" x 5.31" x 3.46"
Weight: 1.04 lbs.
Power Requirements: DC 12~48V, 5A max.
Unit Output Voltage: DC 54V
Power Consumption: 120 watts max.
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3bt 4-pair Power over Ethernet Type 4
IEEE 802.3at Power over Ethernet Plus
Package Contents:
IPOE-171-95W
User's manual
Wall-mount kit
Dust capModel #: IPOE-171-95W
Quick View
Planet LRP-101U-KIT 1-Port Long Reach PoE Over UTP Extender Kit (LRP-101UH + LRP-101UE)Type: PoE ExtenderColor: BlackSpecifications: Ethernet Interface:
LRP-101UH
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PD (Powered Device)
PoE Input: Supports both mid-span and end-span PSE
Input Range: 48~56V DC
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100m
Maximum Frame Size: 1522 bytes
LRP-101UE
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PSE (Power Source Equipment)
PoE Output: 48~56V DC, 600mA max.
PoE Budget: Up to 25 watts
PoE Mode: End-span, RJ45 Pin 1/2 (+), 3/6 (-)
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100m
Maximum Frame Size: 1522 bytes
LED Indicators:
LRP-101UH
4 x LEDs
PWR
LRP LNK
PoE IN
LNK / ACT
LRP-101UE
4 x LEDs
PWR
LRP LNK
PoE-in-u...Model #: LRP-101U-KIT
Quick View
StarTech.com PoE+ Industrial Fiber to Ethernet Media Converter 60W - SFP to RJ45 - SM/MM Fiber to Gigabit Copper IP-30Part Number: IMC1GSFPType: Media ConverterSpecifications: Interfaces/Ports
Total Number of Ports:
1
Network (RJ-45):
Yes
Number of PoE (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Single-mode
I/ O Expansions
Total Number of Expansion Slots:
1
Expansion Slot Type:
SFP (mini-GBIC)
Number of SFP Slots:
1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-TX
100Base-TX
100Base-T
Power Description
Power Source:
PoE+
Power Consumption:
60 W
Plug/Connector Type:
Terminal Block (3 Wire)
Type N
Physical Characteristics
Form Factor:
DIN Rail Mountable
Wall Mountable
Height:
1.3"
Width:
3.2"
Depth:
4.1"
Weight (Approximate):
5.40 oz
Miscellaneous
Package Contents...Model #: IMC1GSFP
Quick View
StarTech.com 1.2m 10G SFP+ to SFP+ Direct Attach CablePart Number: JD096CSTType: Network CableSpecifications: Type: 10GBase direct attach cable - SFF-8431/ SFF-8432
Technology: Twinaxial
Features: Passive cable
Length: 4 ft
Connector: SFP+ - latched
Connector (Second End): SFP+ - latched
Color: Black
OEM Manufacturer Equivalent Part Number: HP JD096C
Manufacturer Warranty: 2-year warranty
General
Network Cable Type: 10GBase direct attach cable - SFF-8431/ SFF-8432
Technology: Twinaxial
Jacket Material: PVC
American Wire Gauge (AWG): 30
Impedance: 100 Ohm
Features: Passive cable
Length: 4 ft
Weight: 2.65 oz
Color: Black
Connectivity
Connector: SFP+ - latched
Connector (Second End): SFP+ - latched
Miscellaneous
OEM Manufacturer Equivalent Part Number: HP JD096C
Compliant Standards: MSA, RoHS, FCCModel #: JD096CST
