Primary Ports: 24 x RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type: Auto-MDIX;
Duplex: 10BASE-T / 100BASE-TX: half or full; 1000BASE-T: full only; Ports 1-8 support MACsec
4 x SFP+ 10GbE ports
1 x port expansion module slot
Supports a maximum of 6 SFP+ ports or 2 1/10GBASE-T ports, with optional module
Primary Ports: 48 x RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+);
Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 x SFP
MAC Address Table: 32,768 entries
Power: Frequency: 50/60 Hz
Maximum power rating: 459W
Idle power: 48.6W
PoE power: 370W PoE+
Standards: IEEE 802.1w Rapid Convergence Spanning Tree
IEEE 802.1AB Link Layer Discovery Protocol
IEEE 802.3af Power over Ethernet
IEEE 802.1p Priority
IEEE 802.3x Flow Control
IEEE 802.1D Spanning Tree
IEEE 802.3ad Link Aggregation Control Protocol
IEEE 802.1X Network Login
IEEE 802.1Q GVRP
Primary Ports: 24 RJ-45 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-T)
1 RS-232C DB-9 console port
2 Dual Personality Ports each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an open mini-GBIC slot (for use with mini-GBIC transceivers)
Standards: IEEE 802.1w Rapid Convergence Spanning Tree
IEEE 802.1AB Link Layer Discovery Protocol
IEEE 802.3af Power over Ethernet
IEEE 802.1p Priority
IEEE 802.3x Flow Control
IEEE 802.1D Spanning Tree
IEEE 802.3ad Link Aggregation Control Protocol
IEEE 802.1X Network Login
IEEE 802.1Q GVRP
Primary Ports: 48 RJ-45 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-T)
1 RS-232C DB-9 console port
2 Dual Personality Ports each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an open mini-GBIC slot (for use with mini-GBIC transceivers)
