Primary Port Speed: Total non-blocking throughput 70 Gbps
Switching capacity 140 Gbps
Forwarding rate 104.16 Mpps
LEDs: System Status
Ethernet PoE
Speed/ Link/Activity
SFP Speed/Link/Activity
Power: Power method Universal input, 100—240V AC, 50/60 Hz
Power supply AC/DC, internal, 500W
Supported voltage range 100—240V AC
Max. power consumption Excluding PoE output: 64W
Including PoE output: 500W
Total available PoE 500W
Features: • IP30 rated industrial power supply with integrated DIN-rail mount
• Provides up to 120 Watts of power (48 V, 2.5 A)
• Built-in active PFC (PF > 0.93)
• Short circuit/overload/over voltage/over temperature protection
• High efficiency (91%) design
• UL 508 approved
• 100 % full load burn-in test
• Extreme -25 to 70 °C
Features: • 4 x Fast Ethernet PoE+ ports
• 1 x Fast Ethernet port
• Up to 90W PoE power budget
• 1Gbps switching capacity
• Hardened IP50 rated aluminum switch
• Extreme operating temperature range of -40° – 75°C (-40° – 167°F)
• Dual inputs provide redundant power with overload current protection
• Includes DIN-Rail mount and wall mount brackets
• Power supply sold separately (model: TI-S15052)
• NDAA
Buffer Memory: M / Total Installed Size: 4 GB
Flash Memory / Installed Size: 4 GB
Power: Power / Device Type: Power Supply
Power / Installed Qty: 2
Power / Provided (W): 1200 Watt
Max Power Consumption: 1183.7 Watt
Power / Voltage Required: 180-240V
Features: • 4 x Gigabit PoE+ ports
• 1 x Gigabit port
• Up to 120W PoE power budget
• Hardened IP50 rated metal switch
• Extreme operating temperature range of -40° – 75°C (-40° – 167°F)
• Dual inputs provide redundant power with overload current protection
• 10Gbps switching capacity
• Includes DIN-Rail mount and wall mount brackets
• Power supply sold separately (model: TI-S15052)
• NDAA / TAA
Power: Power / Device Type: Power Supply
Power / Installed Qty: 2
Power / Provided (W): 1200 Watt
Max Power Consumption: 1183.7 Watt
Power / Voltage Required: 180-240V
Features: 5 x Fast Ethernet ports
1Gbps switching capacity
Hardened IP50 rated aluminum switch
Extreme operating temperature range of -40° – 75° C (40° – 167° F)
Dual power inputs provide redundant power with overload current protection
Fanless design for silent operation
Includes DIN-Rail mount and wall mount brackets
Power supply sold separately (model: TI-M6024)
NDAA / TAA compliant
Lifetime
Primary Ports: 4 x M12 (X-code) Gigabit PoE+ ports
1 x M12 (X-code) Gigabit port
1 x M12 (A-code) power port
LED indicators
Wall mount
Din-Rail mount
Grounding point
Network Media: Media Type Supported:
Twisted Pair
Ethernet Technology:
5 Gigabit Ethernet
2.5 Gigabit Ethernet
Network Technology:
5GBase-T
2.5GBase-T
Maximum Data Transfer Rate:
640 MB/s
Uplink Interface: Total Number of Network Ports:
7
Network (RJ-45):
Yes
Port/Expansion Slot Details:
5 x Gigabit Ethernet PoE+
2 x 2.5 Gigabit Ethernet PoE+
Power: PoE (RJ-45) Port: Yes
PoE Budget: 70 W
Input Voltage:
120 V AC
230 V AC
Frequency:
50 Hz
60 Hz
Power Source: Power Supply
Power Consumption: 8 W
Features: 5 x Gigabit Ethernet ports
Hardened IP50 rated metal switch
Extreme operating temperature range of -40° – 75° C (-40° – 167° F)
Dual power inputs provide redundant power with overload current protection
Fanless design for silent operation
10Gbps switching capacity
Includes DIN-Rail mount and wall mount brackets
Power supply sold separately (model: TI-M6024)
NDAA / TAA compliant
Lifetime
